Edge Construction Supply - page 276

www.edgecs.com
276
Hand Tools
Spokane, WA 509-535-9841 Billings, MT 406-248-7196
Yakima, WA 509-248-1144 Gillette, WY 307-682-8522
TRIUMPH TWIST DRILL CO.
Screw Extractors
• Carbon Steel/Gray
• Remove broken screws, bolts and studs quickly and easily
• Heat-treated finish to resist rust
• Also for turning threaded pipe sections
TRIUMPH TWIST DRILL CO.
Tap & Die Set
HSS
• T513 - Molded Case
• 1/4–20 NC, 5/16–18 NC, 3/8–16
NC, 7/16–14 NC, 1/2–13 NC,
4–40 NC, 6–32 NC, 8–32 NC,
10–24 NC, 12–24 NC, 1/4–28 NF,
5/16–24 NF, 3/8–24 NF, 7/16–20 NF,1/2–20 NF, 10–32 NF, 4–36
NS
• Accessories Include: 1/8–27 NPT Hex Die, TRD50 Hex Die Stock,
1/8–27 NPT Pipe Tap, JT40 Tap Wrench, JT20 Tap Wrench
TRIUMPH TWIST DRILL CO.
Tap & Die Set
38-Piece
• Molded Case with 17 Plug Taps,
16 Round Dies (1” O.D.)
• 1/4–20 NC, 5/16–18 NC, 3/8–16
NC, 7/16–14 NC, 1/2–13 NC,
4–40 NC, 6–32 NC, 8–32 NC,
10–24 NC, 12–24 NC, 1/4–28 NF, 5/16–24 NF, 3/8–24 NF, 7/16–20
NF, 1/2–20 NF,
10–32 NF, 4–36 NS
• Accessories Include: 1/8–27 NPT Round Dies, 1/8–27 NPT Pipe
Tap, TRD47 Round Die Stock, JT20 Tap Wrench, JT40 Tap
Wrench
TRIUMPH TWIST DRILL CO.
Hex Rethreading Dies
Heavy-Duty
• W109HD Fractional
• Dies made the same size as
matching nut, eliminating the
need for more than one wrench
• Used to repair badly damaged or
rusted threads
• Designed to chase damaged
threads, nicks and burrs without
undercutting good threads
TRIUMPH TWIST DRILL CO.
Alignment Reamers
• 1/2” Shank, (77280 has 3/8 shank)
• High Speed Steel
• Black and Bronze Oxide
• 3 flats on shank prevents slippage in
3-jaw chuck
• Collar stop to prevent damage to drill chuck
• Made In USA
Item #
Screw
Ext. # For Removing Screw Size:
Use Drill
Size:
T13CX
TR98136 6 ⁵⁄₈ to ⁷⁄₈, ³⁄₈ Pipe ²⁵⁄₆₄ to ²⁷⁄₆₄
TR98137 7 ⁷⁄₈ to 1¹⁄₈, ¹⁄₂ Pipe ³³⁄₆₄ to ³⁵⁄₆₄
TR98138 8 1¹⁄₈ to 1³⁄₈, ³⁄₄ Pipe ²⁵⁄₃₂ to ²⁷⁄₃₂
TR98139 9 1³⁄₈ and Up, 1 Inch Pipe 1¹⁄₁₆ to 1¹⁄₈
BP13CX
TR98231 1 ³⁄₃₂ to ⁵⁄₃₂ ¹⁄₁₆ to ⁵⁄₆₄
TR98232 2 ⁵⁄₃₂ to ⁷⁄₃₂ ³⁄₃₂ to ⁷⁄₆₄
TR98233 3 ⁷⁄₃₂ to ⁹⁄₃₂ ⁹⁄₆₄ to ⁵⁄₃₂
TR98234 4 ⁹⁄₃₂ to ³⁄₈ ⁷⁄₃₂ to ¹⁄₄
TR98235 5 ³⁄₈ to ⁵⁄₈, ¹⁄₈ & ¹⁄₄ Pipe ¹⁷⁄₆₄ to ¹⁹⁄₆₄
Item #
TR69963
Item #
TR69961
Item # Size-Pitch Thread Across Flats
TR69550 ¹⁄₄-20 NC ¹⁹⁄₃₂
TR69551 ¹⁄₄-28 NF ¹⁹⁄₃₂
TR69552 ⁵⁄₁₆-18 NC ¹¹⁄₁₆
TR69553 ⁵⁄₁₆-24 NF ¹¹⁄₁₆
TR69554 ³⁄₈-16 NC ²⁵⁄₃₂
TR69555 ³⁄₈ -24 NF ²⁵⁄₃₂
TR69556 ⁷⁄₁₆-14 NC ⁷⁄₈
TR69557 ⁷⁄₁₆-20 NF ⁷⁄₈
TR69558 ¹⁄₂-13 NC 1-¹⁄₁₆
TR69559 ¹⁄₂-20 NF 1-¹⁄₁₆
TR69560 ⁹⁄₁₆-12 NC 1-¹⁄₁₆
TR69561 ⁹⁄₁₆-18 NF 1-¹⁄₁₆
TR69562 ⁵⁄₈-11 NC 1-¹⁄₄
TR69563 ⁵⁄₈-11 NF 1-¹⁄₄
TR69566 ³⁄₄-10 NC 1-⁷⁄₁₆
TR69567 ³⁄₄-16 NF 1-⁷⁄₁₆
TR69568 ⁷⁄₈-9 NC 1-⁵⁄₈
TR69569 ⁷⁄₈-14 NF 1-⁵⁄₈
TR69570 1-8 NC 1-¹³⁄₁₆
TR69547 ¹⁄₈ -27 NPT ²⁵⁄₃₂
TR69548 ¹⁄₄-18 NPT 1-¹⁄₁₆
TR69549 ³⁄₈-18 NPT 1-¹⁄₄
TR69577 ¹⁄₂-14 NPT 1-⁷⁄₁₆
TR69578 ³⁄₄-14 NPT 1-¹³⁄₁₆
Item # Size
Decimal
Equivalent Flute Length
Overall
Length
TR72280 ³⁄₈ .3750 3 5
TR72281 ¹⁄₂ .5000 3¹⁵⁄₁₆ 5 ¹⁵⁄₁₆
TR72282 ⁹⁄₁₆ .5625 3¹⁵⁄₁₆ 5 ¹⁵⁄₁₆
TR72283 ⁵⁄₈ .6250 4¹⁄₂ 6⁹⁄₁₆
TR72284 ¹¹⁄₁₆ .6875 4¹⁄₂ 6⁹⁄₁₆
TR72285 ³⁄₄ .7500 4¹⁵⁄₁₆ 7
TR72286 ¹³⁄₁₆ .8125 4¹⁵⁄₁₆ 7
TR72287 ⁷⁄₈ .8750 5³⁄₁₆ 7¹⁄₄
TR72289 1” 1.000 5³⁄₁₆ 7¹⁄₄
