www.edgecs.com
314
Safety & Security
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
DBI/SALA
Horizontal Lifelines
EZ-Line™
•
Retractable lifeline is simply pulled
out for installation and retracted
with built-in winch for dismantle
•
Customize you system length in any
increment up to 60’
•
Built-in tension and impact
indicators take the guess work out
of set up and service
•
Attaches to any 5000 lb. rated anchorage connector or stanchion
for added versatility
•
Provides hands free horizontal mobility and protection for 2 users
per span, up to 6 users per system
•
Meets OSHA, CSA, and EN795 Class C requirements
DBI/SALA
Roof Anchors
Permanent
•
Simply install by clamping onto joist,
rafter, etc. (roof member)
•
Complete with integral D-ring anchorage
point
•
Weather tight cap protects the anchor
from corrosion by sealing it from the
environment
•
Complete with thermoplastic flashing to
prevent water leakage through the roof
•
5,000 lb. Minimum breaking strength
DBI/SALA
Roof Anchors
Reusable
•
Nail into the sheathing and joist,
rafter, etc. (roof member)
•
Steel construction
•
Includes 20 16D nails for single
use
•
3 lbs. total weight
•
Complete with cadmium plated forged alloy steel D-ring
•
5,000 lb. Minimum breaking strength
DBI/SALA
Roof Anchor
Reusable
•
Chain and O-ring
•
25" long
•
Nail or screw into place
DBI/SALA
Roof Anchors
Disposable
•
Quickly installed by first bending the
anchor into shape and conforming it to the
roof; then simply nail it into place through
sheathing and truss on the roof or peak
using ten 16d nails
•
Material: Zinc plated steel
•
Capacity: 310 lbs.
•
Breaking Strength: 1,800 lbs. - rated for fall
arrest
DBI/SALA
D-Ring Anchorage
Plate
•
Bolt or weld to structure
•
Two 1/2" dia. attachment holes
•
Plate size 1/4" x 2" x 4-1/4"
•
Stainless steel plate, zinc plated
D-ring
DBI/SALA
Sliding Beam Anchor
Glyder2™
•
Provides complete horizontal
mobility, tie-off overhead or at your
feet (use with Force2 shock
absorbing lanyard when used at
your feet)
•
Integrated ratcheting adjustment
system provides quick and easy
installation and removal
•
Unique guarded locking
mechanism protects the anchor from accidental disengagement
•
Extremely lightweight at only 3.7 lbs., with a user capacity of 420
lbs. and a minimum breaking strength of 5,000 lbs.
•
Replaceable synthetic wear pads
•
Fits flange 3-1/2” to 14” wide and up to 1-1/4” thick
Item #
DI7605060
Item #
Fits
DI2103670
2x8
DI2103671
2x10 to 2x12
Item #
DI2103676
Item #
DI2103673
Item #
DI2103680
Item #
DI2101630
Item #
DI2104700
