www.edgecs.com
398
Heating, Cooling, Fans & Pumps
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
TPI CORPORATION
Industrial Workstation
Floor Fans
•
3 speed portable fan
•
Head tilts 360°
•
Coated steel guards
•
SJT type 3 conductor, 10’ long cord
•
Steel hub/spider aluminum paddle
blades
•
Meets OSHA standards
TPI CORPORATION
Fan Forced
Milkhouse Heater
•
Heat settings plus fan only setting
•
Temperature control thermostat
•
6' long - 3 conductor cord
•
Triple safety system: Tip over switch,
Automatic reset type limit control, Thermal
cut-off device
TPI CORPORATION
Combination Radiant
& Fan Forced Heaters
•
3-Heat settings
•
Temperature control thermostat
•
Dual safety system: Tip over switch, Manual reset type limit control
•
6' long - 3 conductor cord
TPI CORPORATION
Portable Metal Sheath Electric Infrared Heater
•
Double side wall housings to reduce operating temperatures
•
6.0 and 13.5KW heaters have double top baffles to reduce operating temperatures
•
60° symmetrical heat pattern.
•
Factory installed U-shaped metal sheath infrared heating elements have an average 5000 hour life
•
Heavy duty protective wire screens.
•
GOLD anodized Aluminum internal reflector
•
Ground fault protection must be used
•
2.0 KW and 4.5KW are stand models, 6.0 KW and 13.5 KW are hand cart models
Item # Size
CFM
(High/Medium/Low) Amps
Weight
(lbs.)
TPIF-24-TE 24”
5850/5200/3600 2.4
23
Item # Volts Watts Phase Max. BTU's/Hr.
TPI188TASA 120 1500/1300
Fan Only
1
5120
Item #
Volts
Watts
Phase
Max. BTU's/Hr.
TPI198TMC 120
1500/900/600
1
5120
Item #
KW BTU’s Volts Phase Amps Weight (lbs.)
TPIFHK-224-1A 2.0 6,826 240 1
8.3
17
TPIFHK-248-1A 2.0 6,826 480 1
4.2
17
TPIFHK-424-1A 4.5 15,359 240 1
18.8
24
TPIFHK-448-1A 4.5 15,359 480 1
9.4
24
TPIFHK-624-3A 6.0 20,478 240 3/1 14.4/25.0
37
TPIFHK-648-3A 6.0 20,478 480 3/1
7.5/13
37
TPIFHK-1324-3A 13.5 46,076 240 3
33.0
65
TPIFHK-1348-3A 13.5 46,076 480 3/1 17.0/29.0
65
