www.edgecs.com
40
Power Tools & Accessories
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
HEPA Dust Extraction for
L-Shape SDS Hammer
DeWalt
•
For use with D25303, D25304,
D25313, D25314, D25323, and
D25324 hammers
•
HEPA filter delivers 95% efficiency at
0.3 microns
•
Built-in motor keeps performance high while drilling
•
2-second power-off delay allows dust extraction to continue after
drill is switched off
DeWalt
Large Hammer
Dust Extractor -
Hole Cleaner
•
Two Interchangeable drilling heads for optimum dust removal. One
for holes up to 1-1/2" and one for holes up to 2"
•
Tough Rubber Seal allows for adhesion to most masonry surfaces
•
Two Hole Cleaning Nozzles Match nozzle to hole size for optimal
hole cleaning.
•
Fits DW Universal Hose Connector which allows for quick
connection to hose & swivel capability
SDS Max
Rotary Hammer
1-3/4”
DeWalt
•
13.5 Amp high-performance
motor provides high perfor-
mance; 210-415 rpm; 1430-2840
bpm
•
9.5 ft-lbs. of Impact Energy provides fast drilling and powerful
chipping
•
Shocks - Active Vibration Control® reduces vibration up to 50%
•
Complete Torque Control (CTC)® - Patented 2-Stage clutch
provides maximum control in bind up situations
•
Rear handle mount increases user comfort
•
Trigger lock-on reduces user fatigue while chipping
SDS Max Combination
Hammer
1-7/8"
DeWalt
•
Shocks – Active Vibration
Control® reduces vibration up to
50%
•
Complete Torque Control (CTC)® - Patented 2 Stage clutch
provides maximum control in bind up situations
•
13 Amp motor provides maximum performance; 210-415 rpm;
1430-2840 bpm
•
11.7 ft lbs. of Impact Energy
•
Rear handle mount means less bending over when using tool in
downward chipping applications
•
Trigger Lock On provides increased user comfort in extended use
chipping applications
SDS Max
Combination
Hammer
2"
DeWalt
•
Shocks – Active Vibration Con-
trol® reduces vibration by up to 50%
•
Complete Torque Control (CTC)® utilizes patented 2-stage clutch
for maximum control in bind-up situations
•
15 Amp motor provides maximum overload protection & power
•
15 ft-lbs of impact energy provides maximum performance in
drilling & chipping
•
Rear handle mount means less bending over when using tool in
down drilling applications
•
Lock-on slide switch provides increased user comfort in extended
use applications
1-9/16" SDS Max Combination Hammer Kit
DeWalt
•
12 Amp Motor provides high
performance & overload
protection;490 rpm' 3300 bpm
•
8.0 ft lbs. of Impact Energy
provides fast drilling and
powerful chipping
•
Rear Handle Mount for
increased user comfort in down
drilling applications
•
Factory Set Clutch reduces sudden, high torque reactions if bit
jams
•
Rubber Grip helps reduce the level of vibration felt by the user
•
Lightweight 13.5 lbs
•
Includes: 360 side handle, Kit Box
Item #
DTD25300DH
Item #
DTDWH050K
Item #
DTD25602K
Item #
DTD25712K
Item #
DTD25762K
Item #
DTD25501K
