www.edgecs.com
618
Abrasives
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
PFERD ABRASIVES
POLIFAN® Flap Discs
Silicon Carbide, SG-Elastic
•
Professional tool for grinding on
hard to machine metals, plastics
and masonry products.
•
Workpiece Materials: Titanium,
aluminum, fiberglass, plastics,
masonry
•
Application: Surface grinding, edge
grinding
PFERD ABRASIVES
POLIFAN® Flap Discs
POLIFAN®-STRONG
•
Fastest possible stock removal
rates
•
Extended flap length allows for
aggressive grinding
•
Extremely long tool life
•
Abrasive: Zirconia aluminia Z
•
Workpiece Materials: Steel
•
Application: Work on weld seams, chamfering, deburring
PFERD ABRASIVES
POLIFAN® Flap Discs
POLIFAN®-CURVE
•
Multipurpose - may be used in
conventional and underhand
applications
•
Achieves smooth, consistent
surface finish on fillet welds
•
Abrasive: Zirconia alumina Z (40 grit)
•
Workpiece Materials: Steel, stainless steel (INOX)
•
Application: Fillet weld grinding, chamfering, deburring
PFERD ABRASIVES
DOUDISC®
Combination Cutting
and Grinding Wheels
DUODISC®
The new DUODISC® combination
abrasive wheel is a cost-efficient
and technically advanced solution
for users needing a fast, time-saving
cutting action and reliable deburring
performance - now delivered by a
single wheel!
DUODISC® combination cutting, light deburring and surface grinding
wheels conform to U.S. and international safety standards. Suitable
for both cutting and grinding of Steel and Stainless Steel. DUODISC®
is manufactured without addition of ferrous, sulphurous or chlorinated
fillers. Enjoy long service life and fact cutting action with angle grind-
ers of all power outputs.
•
Type 27 depressed center
Available in two thicknesses:
•
.065 thickness for faster cutting with less material waste.
•
1/8 thickness for maximum tool life and high lateral stability
Item #
Type
Dia.
(in.)
Thickness
(in.)
Grit
Max.
RPM
Flat (PFF-Type 27)-
⁷⁄₈
" Unthreaded Arbor Hole
PF62124 Unthreaded
Arbor Hole
4
¹⁄₂
³⁄₄
24 13,300
PF62125 Unthreaded
Arbor Hole
4
¹⁄₂
³⁄₄
40 13,300
PF62126 Unthreaded
Arbor Hole
4
¹⁄₂
⁵⁄₈
80 13,300
Item #
Diameter
(in.)
Thickness
(in.)
Grit
Bore (in.)
Max
(RPM)
Conical (PFC - Type 29)
PF62945 4
¹⁄₂
9/16
36
7/8 13,300
PF62947 4
¹⁄₂
1/2
50
7/8 13,300
PF62955
5
9/16
36
7/8 12,200
Item #
Diameter
(in.)
Fillet Weld
Width (in.)
Bore Max (RPM)
Radial Shape (PFR)
PF67339
4
¹⁄₂
Large >
⁵⁄₁₆
⁷⁄₈
13,300
PF67359
4
¹⁄₂
Large >
⁵⁄₁₆
⁵⁄₈
-11
13,300
PF67343
5
Large >
⁵⁄₁₆
⁷⁄₈
12,200
PF67363
5
Large >
⁵⁄₁₆
⁵⁄₈
-11
12,200
Item #
Diameter (in.)
Bore (in.)
PF63320
4
¹⁄₂
x .065
⁷⁄₈
PF63333
4
¹⁄₂
x
¹⁄₈
⁷⁄₈
PF63321
5 x .065
⁷⁄₈
PF63334
5 x
¹⁄₈
⁷⁄₈
