629
SPECIFIED TECHNOLOGIES
Cast-In
Firestop Device
SpecSeal®
•
The devices install easily and
quickly. Simply position the
sleeves as required, fasten to the
form and pour the concrete
•
The molded plastic body can be
cut to adjust to the depth of the
pour and is tough enough to resist the rigors of the concrete
finishing process
•
A variety of accessories permit installation under many
construction conditions including variations in concrete depth and
installation over pan decks
•
The unique chambered intumescent system expands rapidly in the
event of a fire to provide up to a three hour fire rating. A resilient
gasket system seals against the propagation of smoke and
provides additional protection against water exposure
•
UL listed products
Application:
•
2”, 3”, 4” and 6” trade size plastic or metallic pipes
•
Insulated metallic pipes
•
Cable bundles
•
Concrete ranging in depth from 2-1/2” to 8”
•
Concrete greater than 8” using available extension tubes
•
Concrete over steel deck using available Deck Adapter Kit
•
Do not use for wall applications
Dimensions:
•
2” ID: Footprint 5-1/8” x 5-1/8” ; Min. Steel Deck Opening 3-5/8”
•
3” ID: Footprint 5-3/4” x 5-3/4” ; Min. Steel Deck Opening 4-1/4”
•
4” ID: Footprint 6-3/4” x 6-3/4” ; Min. Steel Deck Opening 5-1/4”
•
6” ID: Footprint 9” x 9” ; Min. Steel Deck Opening 7-1/4”
•
SpecSeal® Cast-In Firestop Devices have been successfully
tested in accordance with ASTM E814 (ANSI/UL1479) in one, two
and three hour fire-rated floor assemblies. Consult Edge for
individual system designs and application requirements
SPECIFIED TECHNOLOGIES
T-Collar™ Penetrant
Heat Sinking Device
SpecSeal®
•
The SpecSeal® T-Collar™ Penetrant Heat-
Sinking Device is a patented design utilizing
sealed thermal heat sink packs, protected by a
strong metal outer shell
•
The device is secured directly to metal pipes
or conduits on the top side of floors or on both
sides of walls
•
Combined with appropriate SpecSeal® Firestop Products , UL
Systems incorporating this device have been tested to provide T
ratings up to 2 hours
•
Easy to Install
•
Requires no ampacity derating; safer than insulating
•
Code Compliant solutions for T ratings
•
Easily identifiable to ease the inspection process
•
Where codes require equal F and T ratings, the SpecSeal®
T-Collar™ (in conjunction with appropriate SpecSeal® Firestop
Sealants) is used as a heat-sinking device to reduce temperature
transmission through metallic pipes and conduits
•
SpecSeal® T-Collar™ Penetrant Heat Sinking Devices have been
successfully tested in conjunction with SpecSeal® Firestop
Products in accordance with ASTM E814, ANSI/UL1479, and for
individual system designs and application requirements
SPECIFIED TECHNOLOGIES
Firestop Warning
Stickers
•
Label "Warning Firestop
Penetration" Labels for future
maintenance of areas where
firestop is in use
Item #
Desc.
Case Qty.
Devices for Combustible and Noncombustible Penetrants
STICD200 2” Trade Size Cast-In Firestop Device
6
STICD300 3” Trade Size Cast-In Firestop Device
6
STICD400 4” Trade Size Cast-In Firestop Device
6
STICD600 6” Trade Size Cast-In Firestop Device
6
Devices for Non-Combustible Penetrants
STICD200M 2” Trade Size Cast-In Firestop Device
6
STICD300M 3” Trade Size Cast-In Firestop Device
6
STICD400M 4” Trade Size Cast-In Firestop Device
6
STICD600M 6” Trade Size Cast-In Firestop Device
6
Extension Tubes
STICD200X 2” Trade Size Extension Tube
6
STICD300X 3” Trade Size Extension Tube
6
STICD400X 4” Trade Size Extension tube
6
STICD600X 6” Trade Size Extension Tube
6
Deck Adaptor Kits
STICD200K 2” Trade Size Metal Deck Adaptor
6
STICD300K 3” Trade Size Metal Deck Adaptor
6
STICD400K 4” Trade Size Metal Deck Adaptor
6
STICD600K 6” Trade Size Metal Deck Adaptor
6
Item #
Desc.
STITC200 2” Penetrant Heat Seeking Device
STITC300 3” Penetrant Heat Seeking Device
STITC400 4” Penetrant Heat Seeking Device
Item #
STIZ1005-892-CG
Item #
Desc.
Case Qty.
Ask an Edge sales rep
about other time saving
products from STI
