Knockout Punch Kit
Parts
GREENLEE TEXTRON INC.
Knockout Punch Kits
Manual
Slug Buster®
•
Assortment of commonly used
Slug-Buster® knockout punches,
packaged to meet the contractor's
needs
•
High-impact, rugged plastic
carrying case
GREENLEE TEXTRON INC.
Hydraulic Punch
Driver Kit Parts
GREENLEE TEXTRON INC.
Hydraulic Punch
Driver and Kits
Quick Draw®
•
Compact, lightweight design for
portability and fast, easy
one-person operation
•
Develops 8 tons of hydraulic force
for easy punching, even in 10-gauge stainless steel depending on
individual punch capacities
•
Quick Draw® is perfect for fast, straight-on front panel punching
•
Quick Draw 90®'s right angle driver head rotates over 180 degrees
for maximum flexibility in tight working areas
•
Quick Draw® Flex allows unlimited driver orientation to simplify
access to work area
GREENLEE TEXTRON INC.
Hydraulic Punch Driver
and Kits
The Quick Draw™ and the Quick Draw 90™
Features:
•
Optional step-saver adapter converts stan-
dard Greenlee punches thru 1-1/4 inch con-
duit sizes to use 7/16 inch draw stud
(adapter and draw stud included with 7804SB only)
•
Develops 8 tons of hydraulic force for easy punching, even in 10
gauge stainless steel depending on individual punch capacities
•
Quick Draw is perfect for fast, straight-on front panel punching
•
Quick Draw 90's right angle driver head rotates over 180 degrees
for maximum flexibility in tight working areas
GREENLEE TEXTRON INC.
Hydraulic Foot Pump
•
Free both hands to position and hold
the working tool
•
Foot activated release lever
•
Foot Capacity 6,500 psi
Item #
Desc.
Actual Hole Size
Diameter in. (mm)
Included in GR7304 knockout punch kit
GR1429AV 2
¹⁄₂
” Conduit Size Punch 1.951 (49.6)
GR1430AV 2
¹⁄₂
” Conduit Size Die
1.951 (49.6)
GR1431AV 3” Conduit Size Punch
2.416 (61.5)
GR1432AV 3” Conduit Size Die
2.416 (61.5)
Included in GR7610SB Slug-Buster® ram and foot pump
hydraulic driver kit
GR2981AV 3
¹⁄₂
” Conduit Size Die
4.044
GR2982AV 3
¹⁄₂
” Conduit Size Punch
4.044
GR2983AV 4” Conduit Size Die
4.544
GR2984AV 4” Conduit Size Punch
4.544
Included in GR7625, GR7606SB, GR7610SB 4.544
Slug-Buster® ram and foot pump hydraulic driver kit
GR2113AA Draw Stud -
³⁄₄
x 5
³⁄₈
Item #
Conduit Size
GR7235BB
¹⁄₂
- 1
¹⁄₄
in.
GR7237BB 1
¹⁄₂
and 2 in.
Item #
Desc.
Size (in.)
GR31872
Draw Stud
³⁄₄
x 4
¹⁄₈
GR33967 Stud Adapter
³⁄₈
GR1614SS Draw Stud
³⁄₈
x 2
¹³⁄₁₆
Item #
Desc.
GR7706SB Standard - Quick Draw® Flex Driver,
¹⁄₂
in.
through 2 in. Slug Buster® Conduit Size
Punches and Dies, 2 Draw Studs, 1 Adapter,
1 Spacer and Case
Item #
Desc.
GR7806SB Standard - Quick Draw™ Driver,
¹⁄₂
" thru 2" Slug
Buster conduit size punches and dies 2 draw
studs, 1 adapter, 1 spacer and case
GR7904SB Quick Draw 90® Driver, 2 Draw Studs, 1 Adapter,
1 Spacer and Case
GR7906SB Quick Draw 90™ Driver
¹⁄₂
" thru 2" Slug-Buster
conduit size punches, dies and draw studs and
case
Item #
