Electrical Tools
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
GREENLEE TEXTRON INC.
Oiltight Punch Units
•
With notches
•
Includes punch die and draw
stud
•
Maximum Mild Steel Capacity: 10 ga., Operation Type:
Hand/Hydraulic, Minimum Pilot Hole Diameter: .625 in.
GREENLEE TEXTRON INC.
Keyway Punches
•
Eliminates time consuming hand
sawing and filing when making
keyways for push button switches
•
Use as a nibbler to make wider or
deeper keyways
•
Punches 1/8" (3.2 mm) or 3/16"
(4.8 mm) keyways for 7/8" (22.5 mm) or 1-7/32" (30.5 mm) push
button holes
•
Capacity: 10 gauge (3.5 mm) mild steel
GREENLEE TEXTRON INC.
Plumber Stud Punch
•
Punches 2-5/8" diameter hole in
metal studs for professional
looking installation of 2" water,
vent, waste pipes
•
Two-speed lever action for fast,
easy punching of 24 to 20 gauge thick metal studs
•
2-1/8" throat width fits over most studs and channels
GREENLEE TEXTRON INC.
Metal Stud Punches
•
Punch up through 20 gauge steel
studs in one stroke
•
Aluminum head provides strength
with minimum weight, reducing
operator fatigue
•
Contoured handle design gives better operator leverage and
makes it possible to punch in tight places
•
Automatically centers holes on standard studs
Specifications:
•
Capacity: 709 - 1-5/8" and wider studs, 20 gauge steel studs;
710 - 2-1/2" and wider studs, 20 gauge steel studs
GREENLEE TEXTRON INC.
Stud Punches
Manual
•
Punch up through 20 gauge steel
studs in one stroke
•
Unique patented punch rolls the edge over for smooth installation
of armored cable; cable won't hang up
•
Automatically centers holes on standard studs
Actual Hole Size: 1-1/4 in., Capacity: 24 - 20 ga.
GREENLEE TEXTRON INC.
Drill/Tap/CountersinkBits
•
Material thickness - 10 gauge
•
Material type - mild steel, copper,
brass, aluminum
•
Shank - 1/4" quick change hex
GREENLEE TEXTRON INC.
Multi-Hole Step Bits
GREENLEE TEXTRON INC.
Multi-Hole Step Bits
1/2" (12.7 mm) Multi-hole bits allow you to
drill a hole in any of the stated diameters.
3/1 6" 4.8 mm 1/4" 6.4 mm 5/16" 7.9 mm
3/8" 9.5 mm 7/16" 11.1 mm 1/2" 12.7 mm.
•
Unique split tip design penetrates
through steel faster
•
Resists walking or skidding, even on
round surfaces
•
Hole Sizes: From 3/16" through 1/2" (4.8 - 12.7 mm)
•
Capacity: Cut up through 3/8" (9.5 mm) mild steel, copper, brass,
aluminum, wood, plastic and laminates
•
Overall Length 3-3/16" (81.0 mm)
•
Minimum Chuck Size 1/4" (6.4 mm)
Item #
GR60242
Item #
GR720
Item #
GR713
Item #
Desc.
GR709
⁷⁄₈
” (22.2 mm) Diameter Stud Punch
GR710
1
¹¹⁄₃₂
” (34.1 mm) Diameter Stud Punch
Item #
GR724
Item #
Size
GRDTAP3/8-16
³⁄₈
-16
GRDTAP5/16-18
⁵⁄₁₆
-18
GRDTAP1/4-20
¹⁄₄
-20
GRDTAP10-24
10-24
GRGRDTAP12-24 12-24
GRDTAP6-32
6-32
GRDTAP8-32
8-32
GRDTAP10-32
10-32
GRDTAPKIT
Item #
Size (in.)
GR34401
¹⁄₂
GR34403
⁷⁄₈
GR30008
1
¹⁄₈
Item #
GR36402
