GREENLEE TEXTRON INC.
Cable Feeders
Ultra Cable Feeders™
•
Feeds cable at variable speeds to
match the speed of cable puller
•
Accommodates cable ranging in size up
to 3.5" (88.9 mm) in diameter
•
Sets up easily and can be operated by
just one person
•
Dual motors drive each wheel for trac-
tion on both sides of the cable
•
An optional foot switch is available to control feeding
Specifications:
•
Power Supply: 115 VAC, 15 amps, 60 Hz
•
Speed: 4-36 feet per minute (1.2-11 meters per minute)
•
Maximum Tractive Force: Single Cable - 200 lbs. (.9 kN), All
cables - 800 lbs. (3.5 kN)
•
Cable Capacity: 8 x 250 MCM (120 mm), 6 x 500 MCM (240 mm),
5 x 750 MCM (300 mm)
GREENLEE TEXTRON INC.
Foot Switch
For Cable Pullers
•
Use with 640, 2001, 6001, 6500, or
6800 cable pullers to add foot
control
•
Foot pressure required to operate
GREENLEE TEXTRON INC.
Cable Puller
Ultra Tugger 2
UT-2
Pulling Capabilities:
•
3 x 500 kcmil cable 500' with
2 x 90 deg. bends
•
3 x 500 kcmil cable 250' with 4 x 90 deg. bends
•
8 x 4/0 AWG cable 300' with 3 x 90 deg. bends
GREENLEE TEXTRON INC.
Cable Puller
UT-4
•
4,000 lb. pulling force
•
Two pulling speeds
•
Equipped with pull force gauge
and foot switch
•
Dedicated pulling motor
GREENLEE TEXTRON INC.
Cable Puller
Ultra Tugger®
•
Ultra Tugger® Cable Puller with
Standard Force Gauge, Floor Mount,
Versi-Boom™ System and “T” Stand
includes Extensions and 3”, 3-1/2” & 4”
slip-on Couplers, Elbow, Wheeled
Carriage, Screw-on Couplers, or Rope.
•
Pulls up to 8,000 lbs. Versi-Boom™
System allows you to make versatile
and fast set-ups and pull 10' or 20' of
extra cable easily. Uses standard 3' rigid steel conduit for boom.
Direct gear drive. Lightweight. Portable. Optional deluxe force
gauge.
•
Drive Motor 1-1/2 Horsepower
•
Pulling Force Maximum - 8,000 lbs., Continuous - 6,500 lbs.
•
Rated at 32,000 lbs.
GREENLEE TEXTRON INC.
Hook-Type Sheaves
•
Forged steel closure type hooks with 1” opening
•
Maximum Rated Capacity: 8,000 lbs.
GREENLEE TEXTRON INC.
Adapter Sheaves
Flexible
•
Use to attach to the conduit in
conjunction with adapter sheave for
easier setups
•
Helps eliminate strain on hangers and
boxes
•
Maximum Rated Capacity: 6,500 lbs.
(28.9 kN)
Item #
GR6810
Item #
GR445
Item #
GRUT-2
Item #
GRUT-4
Item #
GR6805A
Item # O.D. (in.)
Inside Radius
(in.)
Width (in.)
GR8012 12
3
⁷⁄₈
5
GR8018 18
7
6
GR8024 24
9
⁷⁄₈
6
¹⁄₂
Item #
GR608
