Circuit Tracer Kit
•
Advanced patented non-directional
sensing technology
•
Superior sensitivity and functionality
providing for accurate tracing and locating
•
Ergonomic receiver with information-rich
full-color graphical LCD
•
Graphics and audible signal provide quick
and easy to understand tracing feedback
•
Traces concealed wiring, locates junction
boxes, and finds breakers for live or open
circuits
•
Locates and identifies blown fuses
•
Finds shorts and breaks in conductors
•
Low pitch, high volume audible indicator
•
User-selectable automatic or manual gain capability for fast,
convenient use
•
Power saving features promote extended battery life
(Auto Power Off)
•
Can be used on GFCI protected circuits
•
Supports transmitter-to-receiver distances up to 4 miles for closed
circuit tracing
•
Does not affect sensitive electronic equipment on the circuit
•
Auto backlight on receiver maximizes battery life
•
Lifetime Limited Warranty
Operating Conditions:
•
Temperature: 0 to +50 ºC (32 to 122 ºF)
•
Altitude: 2000 m (6500’) maximum
•
Pollution Degree: 2
•
Indoor use only
Transmitter:
•
Measurement Category: Category III, 750V
•
Operating Voltage: 0-750 V AC/DC
•
Live line LED indicates voltage above 12 VAC or 5 VDC
•
Frequency: 15.15 kHz
•
Low battery indicator
Receiver:
•
Range from Receiver to item with Signal: Live Line Mode – up to
20 ft (6 m) from circuit, Open Line Mode – Up to 10 ft. (3 m) with a
metallic connection to ground, 1 to 3 ft. (.3 to .9 m) with a
capacitive ground reference
GREENLEE TEXTRON INC.
Mesh Cabinet
•
High-visibility mesh screen on
three (3) sides
•
Forty-eight (48) smaller, individual
compartments, enabling storage
of smaller tools and accessories
•
1/2” conduit support tunnels for
top storage (conduit not included)
•
Supplied with two (2) swivel cast-
ers and two (2) rigid 4” (102 mm) casters for easy mobility (Model
696)
•
Capacity: 37.3 ft.
GREENLEE TEXTRON INC.
Handy Caddies
•
3/8" (9.5 mm) diameter solid
steel spool support spindles
•
Spool retaining washers on
spindles
•
Holds four 500' (152 m) spools of
#10 AWG (7" dia. by 6" - 10"
wide)
•
Holds up to eight 500' (152 m) spools of #12 AWG (7" dia. x 5"
wide)
GREENLEE TEXTRON INC.
Wire Caddies
•
6 wire spool axles with spring clip
locks
•
Pre-drilled caster mounting holes
906:
•
Collapsible wire guide
•
Swivel caster set with 2 locking
casters for easy use
Capacity:
•
Six 500' (152.4 m) spools up to 8" (203.2 mm) in diameter of #6
thru #10 AWG 600 volt wire
GREENLEE TEXTRON INC.
Wire Dispenser
No. 909
•
All steel welded frame with 6 reel
spindles and feeding eye
•
Angled spindles keep reels in place
without locks and help brake the reel
while paying out
•
Mobile, 2 fixed wheels and one that
swivels and locks, allow easy
movement and control
•
Fits through a 30" doorway
GREENLEE TEXTRON INC.
Wire Dispenser
No. 910
•
Base has 2 fixed and 2 swivel
locking heavy duty casters
•
The spool rack consists of 10
spindles and an adjustable guide
loop, and can be turned 360 degree
independent of the base
•
Spindles are angled to contain reels
and act as a brake while paying out
wire
•
Fits through a 36 inch (915 mm) opening
Item #
GRCS-8000
Item #
GR5060 MESH
Item #
GR9502
Item #
GR906
Item #
GR909
Item #
GR910
