GREENLEE TEXTRON INC.
Wire Cart Hand Truck
•
Dual heavy-duty wire guides for dispensing
multiple wires in all directions
•
Only 23" (584.2 mm) wide to fit through narrow
doorways
•
Comes with five 5/8" (15.9 mm) diameter reel
spindles for storing and dispensing up to fifteen
spools of #14 THHN wire
GREENLEE TEXTRON INC.
Wire Utility Cart
•
Large capacity, excellent for storing,
transporting or feeding wire
•
5 strong reel axles with spring clip
retainers plus 2 positions for axle
storage allows you to configure for large
reels with no loose parts
Capacity:
•
Size 2,500' (762 m) spools up to 16"
(406 mm) in diameter; six 500' (152.4
m) spools up to 8" (203 mm) in diameter
GREENLEE TEXTRON INC.
Storage Rack
Conduit and Pipe
•
7 individual bins allow you to sort by
size and type
•
Made of structural square tubing
•
Folds down for storage
•
Capacity lbs. (kg.): 1000 (454)
GREENLEE TEXTRON INC.
Coiled Cable
Dispensers
BX-Armored
•
Dispense armored cable, flexible
conduit, Greenfield® or NM-B
cable fast and easy without twists
or tangles
•
Base with adjustable tension control rotates to dispense the cable
without overpulling
•
Large pulling eye rotates freely and can be used as a carrying
handle when the dispenser is empty
Capacity:
•
One 250' coil or 14/2, 14/3, 12/2 or 12/3 armored cable or romex
GREENLEE TEXTRON INC.
Cable Dispensers
Caddy Basket
•
Fits both 2 x 4 and 2 x 6 studs
•
Dispense coils of NM-B or armored cable
•
Swivel eyelet eliminates tangles
GREENLEE TEXTRON INC.
Reel Stands
Screw Type
•
Wide welded steel base for added stability
•
Roller bearings fit in the spindle groove to
keep the spindle in place and turning freely
•
Two stands and a spindle are required for a
complete set-up
GREENLEE TEXTRON INC.
Reel Stand Spindles
•
Tempered steel with grooves to fit
reel stand rollers
GREENLEE TEXTRON INC.
Threaded Rod Cutter
•
One stroke cuts through threaded
rod; cuts clean, eliminating the
need to grind or file before
threading a nut onto a cut end
•
Strong forged steel cutting head with tool steel cutting die for long
life
Capacity:
•
1/4” – 20 soft steel rod; 3/8” - 16 soft steel rods
Item #
GR38733
Item #
GR911
Item #
GR668
Item #
GR37218
Item #
Desc.
GR9525F Folding Stud Mount Caddy
Item #
Desc.
Capacity
GR683 Reel Stand
22 in. - 54 in.
2,500 lbs. each,
46 in. - 96 in. Reel Diameter
GR687 Reel Stand
13 in. - 28 in.
2,500 lbs. each,
28 in. - 56 in. Reel Diameter
Item #
Desc.
GR647
Spindle for 687 Reel Stands
GR657
Spindle for 656 Reel Stands
GR684
Spindle for 683 Reel Stands
Item #
GR36587
