207
ERICO/CADDY
Weld Metals
CADWELD Weld Metal is a mixture of
copper oxide and aluminum, packaged
by size in plastic tubes. Each tube
contains the starting material at the
bottom of the plastic tube, with the weld
metal on top. These materials are not
explosive and not subject to
spontaneous ignition. These containers
are
packaged in boxes along with metal disks. Each weld uses one disk.
Weld Metals are used for grounding connections:
F20 or standard weld metal is used for all grounding connections with
the exception of those to cast iron or to load bearing rail. The
standard weld metal containers have clear (or natural) caps.
Standard weld metal is also used with most FX molds.
Package: Foil pouch
ERICO/CADDY
Handle Clamps
For C price key molds
ERICO/CADDY
Flint Ignitors
Cadweld flint ignitors are used to ignite
the starting material when making a
Cadweld connection. An ignitor is
included with each handle clamp or
frame. T320A Replacement flints are
also available.
ERICO/CADDY
Weld Metals
The CADWELD PLUS System
offers all the benefits of
conventional CADWELD
connections
Consists of a tamper proof,
disposable, moisture resistant
welding material cup. The welding material, disk and ignition
source are incorporated into the self-contained package
Color coded welding material reduces risk of misapplication and
gives a simple visual verification of the correct welding material
size
Electronic Control Unit means no starting material is required and
makes ignition very easy
Six foot control unit lead gives increased flexibility in hard to reach
areas
ERICO/CADDY
Cadweld® Plus
Ignitor Control Unit
Cadweld
ERICO/CADDY
Mold Sealers
Cadweld Mold Sealer is ideal for
sealing hot or cold molds to retard
leakage from large stranded
conductors
ERICO/CADDY
Cable Cleaning
Brushes
Card cloth brush
Item #
CD25
CD32
CD45
CD65
CD90
CD115
CD150
CD200
CD250
CD500
Item #
CDL-160
Item #
Desc.
CDT320 Flint Igniter
CDT320A Repl. Flints
Item #
CD25PLUSF20
CD32PLUSF20
CD45PLUSF20
CD65PLUSF20
CD90PLUSF20
CD115PLUSF20
CD150PLUSF20
CD200PLUSF20
CD250PLUSF20
Item #
CDPLUSCU
Item #
CDT403
Item #
CDT313
