GENIE INDUSTRIES
Scissor Lift
Electric Self-Propelled
GS™
The solid steel deck platform has a slip-resistant surface
Heavy-duty guardrails fold down quickly without tools for increased accessibility
Built-in lanyard attachment points are provided
Standard Features:
39 in. (1 m) roll-out platform extension
Proportional controls for lift and drive functions
AC wiring to platform
Manual platform lowering valve
Tilt sensor with an audible alarm
Pothole guards
Automatic 25 amp battery charger
Non-marking tires
Hour meter
ASK EDGE FOR MORE DETAILED SPECS
GENIE INDUSTRIES
Scissor Lift
Electric Self-Propelled
GS™
The solid steel deck platform has a slip-resistant surface
Telescopic end rail can be raised to accommodate large loads
Built-in lanyard attachment points
Standard Features:
39 in. (1 m) roll-out platform extension
Compact design
Automatic 25 amp battery charger
Pothole guards
Non-marking tires
AC wiring to platform
Tilt level sensor with an audible alarm
Turning Radius Outside: 61”
Power Source: 24V (4 6V 245AH Batteries)
Drive Speed - Stowed: 0-2.5 mph;Drive Speed - Raised: 0-0.6 mph
Extension Deck Lift Capacity: 250 lbs.
Length - Stowed: 72”
Width: 30”
Wheelbase: 52”
Ground Clearance: 2-5/8”
Platform Length - Outside: 64-3/8”; Platform Width - Outside: 29 1/4”; Platform Length - Extended: 103-3/8”
Guard Height - ANSI/CSA: 39”; Guard Height - CE: 43-3/8”
Gradeability: 30%
Pothole Protection: Standard
Item #
Lift Capacity
ANSI, CE (lbs.)
Raise/Lower
Speed (sec)
Working
Height (ft.)
Platform
Height (ft.)
Height - Stowed
(Guardrails
Folded) (in.)
Height - Stowed
(Guardrails) (in.)
Height - Stowed
(Platform) (in.)
Wt
GNGS-2646
1,000
30/24
32
26
68
89
³⁄₄
46
4530
Item #
Lift Capacity
(lbs.)
Working
Height ft. (in.)
Platform
Height ft. (in.)
Height - Stowed (Guardrails)
ANSI, CSA (in.)
Height - Stowed
(Guardrails) CE (in.)
Height - Stowed
(Platform) (in.)
Wt
GNGS-1530 600
21
15
76
80
36
¹⁄₂
2658
GNGS-1930 500
25 (1)
19 (1)
78
82
¹⁄₂
38
¹⁄₂
2956
