WERNER CO.
Square Modular Guard Rail System
The following steps show how to size a single-side, three-sided, and four-sided guard rail system:
•
Determine the stage length and width
•
Determine whether guardrail
system is one-, two-, three-, or four-sided
•
Read across the row to determine component requirements
•
If ordering a three- or four-sided system, order two ERT-N for 12” and 14” stages, and two ERT-W for all stages 20” wide or greater
•
If ordering a two sided system, double the single sided component requirement
•
CONTACT AN EDGE SALES REP FOR ASSISTANCE
Item #
Desc.
Wt. Lbs.
WEERT-N
End rail and End toe board assembly-narrow
4.5
WEERT-W
End rail and End toe board assembly-wide
7
WESSP-47
Stanchion post assembly
5
WESGR-09
1
¹⁄₂
” square guardtail cut length-108”
6
WESGR-13
1
¹⁄₂
” square guardrail cut length-156”
8.5
WESTB-09
3
¹⁄₂
” toe board cut length-108”
4.5
WESTB-13
3
¹⁄₂
” toe board cut length-156”
6.5
Call an Edge rep today for
help with guardrail systems.
