Material Handling & Storage
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
LIFT-ALL®
Tow-All Vehicle Straps
Tuflex
Tuflex version of the Tow-All straps offers the most rugged synthetic strap on the market. The Tuflex Tow-All is
made up of a standard Tuflex roundsling and adds an additional jacket of texturized, abrasion resistant nylon
over the body of the sling, making it into an eye & eye style. The eyes are then covered with ballistic nylon
webbing for additional protection. An 18 long sliding sleeve wear pad provides added protection against load
edges.
High capacity design
No dangerous hooks or metal parts
Elongates 5% at Towing Capacity to help absorb the energy of sudden loading.
Lightweight, flexible, easy to use and store
All load yarns are protected by multiple layers of webbing
Polyester/nylon material is easy on painted and plated surfaces
Strap design prevents dangerous recoil if broken
•
Add length after item number when ordering
COLUMBUS MCKINNON CORP.
Manual Chain Hoists
Hurricane Series
•
Unique Handwheel Cover - Handwheel cover rotates 360
degrees for hoist operation in any direction
•
Unique Brake Design - Single disc brake does not
incorporate ratchet, pawls,or pawl springs as on other
hand chain hoists
COLUMBUS MCKINNON CORP.
Mini Ratchet Lever Hoist
Series 602/603
•
Plated load chain
•
Weston-type load brake
•
Lightweight design weighs only 5 pounds for
ease of operation and portability; use in
confined conditions with one hand operation
•
Free chaining feature serves to quickly
attach the load
Item #
Assembly Breaking Strength*
Towing Capacity(lbs.)
LFTSEN90
42,000
14,000
LFTSEN120
52,500
17,500
LFTSEN150
66,000
22,000
LFTSEN180
84,000
28,000
LFTSEN240
105,900
35,300
LFTSEN360
154,800
51,600
LFTSEN600
249,900
83,300
LFTSEN800
330,000
110,000
LFTSEN1000
450,000
150,000
* Break Strength when new and unused, do not exceed Towing Capacity
Item #
RatedCap.
(tons)
Standard
Lift (ft.)
Chain Pull
to Lift (lbs.)
Hand Chain to
Overhauled to
Lift 1’ (ft.)
CM5623A
¹⁄₂
10
44
30
CM5624A
¹⁄₂
15
44
30
Item # Rated Cap. (lbs.) Standard Lift (ft.)
CM0210
550
5
CM0214
550
10
CM0215
1,100
5
CM0216
1,100
10
