COLUMBUS MCKINNON CORP.
Pullers
•
Tough aluminum alloy
construction and powder coat
finish
•
Weatherproof for outdoor service
•
Hoistaloy hardened steel link type
load chain for strength, long wear
life and flexibility
•
Weatherized Weston-type auto-
matic braking system for positive
load control
•
Easy, one-hand operation and control — only 58 pounds of pull
required for 3/4 ton model capacity
•
Forged upper and lower hooks with latches standard
•
Free wheeling for fast and easy attachment to load
•
Upper and lower Latchlok hooks available for all capacities
•
Optional Load Limiter protection device stops transmission of lever
forces protecting against dangerous overload
•
Optional Load Sentry warns of overload condition
•
Optional anchor sling simplifies attachment to allow anchor hook
to swivel in tight space applications (3⁄4 & 11⁄2 ton units only)
•
Unlimited lift
•
Lifetime warranty
•
Made in U.S.A.
COLUMBUS MCKINNON CORP.
Wide Range Trolley
Series 633
•
Rugged steel side plates formed to
include bumpers and trolley guards
•
Frames connected by steel
equalizer pin, secured by two nuts
on each side
•
Universal tread flanged trackwheels equipped with shielded ball
bearings
•
Easy rolling on American standard shapes, wide flange shapes or
patented rail
COLUMBUS MCKINNON CORP.
Binders
Tightener Load Binder
•
Features a swivel hook for easier
operation
•
Either hook may be permanently
attached to chain
•
Rugged cast construction with
formed hooks
COLUMBUS MCKINNON CORP.
Binders
Lever Type Load Binder
•
All components are forged, no cast parts
•
Lighter and stronger than cast binders
Item # Rated Capacity (ton)
Standard Unit
CM4043
³⁄₄
CM4045
1
¹⁄₂
CM4047
3
CM4050
6
Kit with Load Limiter
CM4190
³⁄₄
CM4191
1
¹⁄₂
CM4191
3
CM4191
6
Kit with Load Sentry
CM4096
³⁄₄
CM4098
1
¹⁄₂
CM4098
3
CM4098
6
Kit with Anchor Sling
CM4071
³⁄₄
CM4072
1
¹⁄₂
Item #
RatedCap.
(tons)
Depth of
S-Beam (in.)
Flange
Width (in.)
Tread Dia.
(in.)
CM3302
¹⁄₂
3-15
2
¹⁄₂
-5
⁵⁄₈
2
⁹⁄₃₂
CM3304
1
5-24
3-8
3
¹⁵⁄₃₂
CM3306
2
6-24
3
⁵⁄₈
-8
3
¹⁵⁄₁₆
CM3307
3
8-24
4-8
5
¹⁄₈
Item # Working Load Limit (lbs.) Handle Take up ( in.)
CM48949
375
3
Item #
Working Load
Limit (lbs.)
HandleTake
up ( in.)
Working Load
Length (in.)
CM48304
2,600
3.75
11.25
CM48305
5,400
4.50
16.12
CM48406
9,200
4.75
16.62
CM48769
7,100
4.50
16.62
