CHICAGO PNEUMATIC TOOL CO.
Rivet Busters
With CPS
•
Originally designed for cutting and forming metal rivets, the CP buster is now used for concrete demolition and has
become one of the stars of the CP range
•
It has low frequency blow with hitting power equivalent to a paving breaker twice its weight
•
The new CPS includes a stepped piston and step cylinder to prevent accidental ejection of the piston
•
Teasing throttle for progressive hitting frequency gives better control of such a powerful machine
•
Forged steel handle for long life in rugged conditions
•
New buffer ring is now 90 durometer rubber for extra life
Choice of cylinders:
•
11” cylinder
•
8” cylinder
Choice of handle:
•
Open grip with outside trigger
•
“D” handle with inside trigger
•
1/2” inlet bushing
CHICAGO PNEUMATIC TOOL CO.
Combi Drills/Hammers
•
The CPCP 009 and CPCP 0014 RR rotary hammers are designed for a wide variety of construction and
maintenance applications such as driving or setting masonry anchors and drilling holes in concrete, bricks or
rock; as a hammer, these tools can be used for chipping, scarifying,
scaling and cleaning welds
All Models:
•
Excellent power-to-weight ratio helps drill holes faster and easier than comparable electric rotary hammers
•
Built-in oiler provides continuous lubrication
•
Teasing throttle for precise control
•
Rotation release button converts tool to a hammer (except on CPCP 0009 AC)
•
Muffler available to reduce noise
CPCP 009:
•
With an adaptor, can be used with electric hammer drill bits
CPCP 0014:
•
Superior drilling rates
•
Greater drilling capacity compared to plug hole drills
•
Designed for production drilling of small holes
Item #
Blows Per
Minute (bpm)
Cylinder
Stroke (in.)
Length
(in.)
Air Consump.
(cfm)
Air Inlet
(in.)
Chuck Size
(Jumbo Shank)
Handle
Cylinder
CPCP 4608 P 1080
8
23
45
¹⁄₂
.890” x 1.125” Taper
Open grip -
Outside trigger
Short cylinder
CPCP 4611 P 720
11
26
45
¹⁄₂
.890” x 1.125” Taper
Open grip -
Outside trigger
Long cylinder
CPCP 4608 D 1080
8
23
45
¹⁄₂
.890” x 1.125” Taper “D” handle -
Inside trigger
Short cylinder
CPCP 4611 D 720
11
26
45
¹⁄₂
.890” x 1.125” Taper “D” handle -
Inside trigger
Long cylinder
Item #
Net Weight (lbs.) Overall Length (in.) Type of Chuck (in.) Chuck Size (in.)
CPCP 0009 - Air consumption at 90 psi: 20 cfm,
³⁄₈
” (NPT) air inlet thread
CPCP 0009 A
8
14
³⁄₄
round shank
³⁄₄
x 3
³⁄₄
CPCP 0009 AC
8
14
³⁄₄
round shank
³⁄₄
x 3
³⁄₄
CPCP 0009 F
8
14
³⁄₄
spline drive
CPCP 0014 RR - Air consumption at 90 psi: 32 cfm,
³⁄₈
” (NPT) air inlet thread
CPCP 0014 RR
15
18
¹⁄₂
spring hex shank
⁷⁄₈
x 3
¹⁄₄
