Air & Hydraulic Tools
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
GREENLEE TEXTRON INC.
Compact Submersible
Water Pumps
2” Pump
Fairmont
•
Self-priming, compact,
lightweight design with carrying
handle
•
Up to 275 gpm
•
Can draw water down to depth of
1-3/4"
•
Can run dry without damage
Specifications:
•
System: Open-center and closed-center
•
Capacity: Up to 275 gpm (at 7 gpm and a 10’ head height)
•
Flow Range: 5 - 8 gpm
•
Operating Pressure: 0 - 2,000 psi
GREENLEE TEXTRON INC.
Standard Chain Saws
Hydraulic
Fairmont
•
Ideal for large trimming applications
and cut-up removal jobs
•
Chain and bar can be adjusted without removing sprocket cover
•
Handle position can be oriented to horizontal, or to 60º or 30º
relative to bar and chain to user preference (except on model with
chain brake)
•
Rugged gear motor and expanded chip exit area
•
Automatic chain oiler can be adjusted without tools
•
Safety Features Include: Two-step safety trigger, high impact
polymer front handle/shroud, wide lower handle protects
hands/knuckles, chain catcher stops chain rotation
•
Reduced kickback bar and chain
•
Supplied with 12" (305 mm) steel braided whip hoses (couplers
not included)
•
Chain brake models meet requirements of ISO 6535
GREENLEE TEXTRON INC.
Long-Reach
Chain Saws
Hydraulic
Fairmont
•
Cuts hard-to-reach branches
from aerial basket or from the ground
•
Super Spool™ selector control for use on open-center and
closed-center hydraulic systems
•
Available in three lengths
•
Insulated fiberglass extension tubes, tested to meet OSHA
Regulation 1910.269
•
Safety features include: two-step trigger, trigger guard, and fully
covered sprocket guard
•
Anti-kickback chain and automatic chain oiler
•
Unfilled and foam-filled extension tube versions offered
Specifications:
•
Cutting Capacity: 13”
•
Extension Type: Fiberglass-tested to 100 KvA for 5 minutes
GREENLEE TEXTRON INC.
Hydraulic Power Unit
20 Hp
Fairmont
•
Electric key-start 20 hp Honda OHV
engine with low-oil shutdown
•
Variable oil flow to 10 gpm (38 lpm)
•
Oversized oil cooler and electric fan
ensures cool running
•
Engine hour meter and tachometer
•
Hydraulic oil level sight gauge and
10 micron oil filter
•
Tubular frame protects components and allows easy access to
maintenance points
•
Integral grab rails for lifting the unit into trucks and trailers
•
Heavy-duty lifting eye
•
HTMA flat-face hydraulic couplers
•
Easy access service points for engine oil, fuel, battery, and oil filter
•
Sealed lead-acid battery
Specifications:
•
Horsepower: 20 at 3,600 rpm (14.9 kW at 3,600 rpm)
•
System: Open-center
•
Rated Flow: 5 - 10 gpm
•
Rated Pressure: 2,000 psi
•
Fuel: Gasoline 3.3 gal.
•
Hyd Oil Capacity: 3.1 gal.
•
Dry Weight: 259 lb.
Item #
GRH4665A
Item #
Desc.
Cutting
Capacity
(in.)
Weight
(lbs.)
Length
(in.)
GRHCS816 Chain Saw 16
9.5 31.5
GRHCS820 Chain Saw 20
10.2 35.5
GRHCS8160CB Chain Saw
with Chain
Brake
16
9.5 31.5
Item #
Desc.
Length
(in.)
Weight
(lbs.)
GR43178
Long Reach
Chain Saw
62.5
8
¹⁄₂
GR38568
Long Reach
Chain Saw
75
9
¹⁄₄
GR43177
Long Reach
Chain Saw
88.5
9
³⁄₄
GRLRF75
Foam Filled
Long Reach Chain Saw
75
9
¹⁄₂
GRLRF88
Foam Filled
Long Reach Chain Saw
88.5
10
¹⁄₄
Item #
GRF20
