409
DIAMOND PRODUCTS
Complete Drill Rigs
Combination
•
The most lightweight rig of any in its class
(combo stand, wheel kit and switch box weighs
just 52 lbs.)
•
12” bit capacity (up to 36" with spacers and
hydraulic motor and power jack)
•
Easy quick-disconnect motor mount
•
Angle drilling capability up to 45°
•
Easily adjustable slide bearings
•
Longer columns available up to 60"
•
Quick release vacuum button
•
Double column support for increased stability
•
4-spoke sliding handle (can be used on either side)
•
Convenient easy carrying handle (ceiling jack available)
Motor:
•
20 amp core bore CB748, RPM: 350/900
Safety Override:
•
Slip clutch
DIAMOND PRODUCTS
Hand Held Core Drill
WEKA DK12
•
Side handle
•
14 Amp, 110 Volts motor
•
3-speed 580/1400/2900 Rpm
•
Electronic overload
•
Case included
•
5/8-11 and 1.250-7 threaded
spindle
DIAMOND PRODUCTS
Complete Drill Rigs
Light Weight
M1-AA-15
•
15 amp, 3.5HP
•
6 inch bit capacity
•
Weighs only 45 lbs.
•
15 amp, 3.5 HP Core Bore Motor
•
Single speed
•
Water hose connection
•
Spring loaded slide handle for easy coring
•
Includes a water trap ring
DIAMOND PRODUCTS
Complete Drill Rigs
Combination
M-1
•
1" to 10" bit capacity (14" with one spacer)
•
Dual switch/outlet control panel & amp meter
•
Streamlined base and carriage
•
2-1/2" square column with black oxidized finish
•
Quick changeover from vacuum to anchor base
DIAMOND PRODUCTS
Drill Rig Accessories
Vacuum Pumps
•
Gast vacuum pumps mount easily and
run quietly
•
For use with Core Bore drillings
•
Use to suction core rig to surface
DIAMOND PRODUCTS
Complete Drill Rigs
Combination
M-4
•
Weighs only 35 lbs. (rig -20 lbs., motor -15
lbs.)
•
6" bit capacity (3" handheld)
•
Converts to hand held drill motor in sec-
onds
•
Combination Stand quickly angles to 45
degrees
•
3-speed hand held drill motors with overload clutches
•
Mast can rotate 360 degrees on swivel stand
•
Reversible slide handle (use on left side or right side of rig)
DIAMOND PRODUCTS
Cut-Off Saw
SpeediCut
•
Sturdy die-cast magnesium foot
•
Rubber cushioned full
wrap-around handle
Item #
Desc.
RPM Bit Capacity
DP4220003 20 Amp, CB748 350/900
12”
Item #
Desc.
RPM Safety Overide
DP4244017 WEKA DK12,
14 Amp
580/1400/
2900
Slip Clutch
Item #
Desc.
RPM Bit Capacity
DP4220050 15 Amp, 3.5 Hp 800
6”
Item #
Desc.
RPM Safety Overide
DP4245055 20 Amp Core Bore 350/900 Slip Clutch
Item #
Desc.
DP4244077 1/8 Hp
Item #
Desc.
RPM Safety Overide
DP4240001 14 Amp WEKA DK12 580/1400/
2900
Slip Clutch
Accessories
DP4240020 M-4 Drill Stand
Item #
Desc Blade Capacity Weight (lbs.)
DP44071 5.6 Hp
16”
21
