Concrete Tools & Products
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
DIAMOND PRODUCTS
14” Masonry Saw
•
Saw head adjusts easily
•
Longer motor life due to a
superior air filter
•
Includes 2 spare air filters
•
Blade not included
•
Power Supply: 115V/60Hz
•
Power: 2 Horsepower
•
Amp Draw: 15 Amp
•
Max. Depth of Cut: 5"
•
Max Length of Cut: 16"
•
Material Size: 8" x 8" x 16"
•
Weight: 80 lbs.
•
Saw Height: 24"
•
Saw Length: 28"
•
Saw Width: 23"
DIAMOND PRODUCTS
Masonry Saw
Electric
•
Stay level blade guard
•
Removable cutting head
•
Open back cutting allows longer material to be
cut
•
Leg kit standard - folding stand optional
•
Side carrying handles
•
Includes water pump
•
Vulcanized rubber coated materials slide cart
•
Easy and safe access to depth control lock
•
Blade Shaft Diameter: 7/8”
•
Arbor Diameter: 1”
DIAMOND PRODUCTS
Joint Cleaning Saw
•
Upcut or downcut available
•
Heavy duty adjustable handles
•
Water valve can be mounted on
left or right
•
1" arbor size and drive pin
•
11 HP GX-390 Honda engine
•
Blade Shaft Diameter: 1”
•
Arbor Size: 1” Diameter
•
Front Wheels: 3” x 2” x 3/4”
•
Rear Wheels: 8” x 2” x 3/4”
DIAMOND PRODUCTS
Joint Cutting Saw
Center Cut Design
•
Cyclone air cleaner for increased
engine longevity
•
Front and rear pointers
•
Polyurethane wheels with roller
bearings and grease zerks
•
Quick release folding handle
•
Cutting depth up to 2-1/4" with 8 inch blade
•
Power transmission to blade drive is via 2 molded notch 3VX
premium belts - for better cutting performance and longer belt life
•
Center cut design - Better tracking into an existing cut and easy to
keep the cut straight
•
Self adjusting dust guard
•
1" arbor with greaseable bearings
DIAMOND PRODUCTS
Small
Walk Behind Saw
Our patented ratchet raise and
lower system is the fastest, easiest
way to place the blade into and out
of the cut. It has 11 depth settings
to choose from which automatically
lock in place when the handgrip is
released. Settings are in 1/2"
increments.
•
Large wheels for easy mobility over curbs and rough surfaces
•
Removable handles for easy storage
•
Blade coolant is delivered from an innovative dual multi-spray
water tube system which gets coolant to both sides of the blade
from the arbor to the top of the blade
•
Power transmission to blade drive is via 3 molded notch 3VX
premium belts - not 2, like some of our competitors, resulting in
better cutting performance and longer belt life
•
Self aligning blade shaft bearings
•
4-5/8" cutting depth with 14" guard
Specifications:
•
Maximum Depth of Cut: 4-5/8"
•
Blade Shaft: 3,000 RPM
•
Blade Shaft Diameter: 1"
•
Arbor Size: 1" diameter with single drive pin
•
Front Wheels: 5" x 2" x 3/4"
•
Rear Wheels: 8" x 2" x 3/4"
Dimensions:
•
Saw Height: 38"
•
Min. Length, Pointer Up: 37-1/2"
•
Max. Length, Pointer Down: 60"
•
Pointer Extension: 22-1/2"
•
Frame Width: 12-3/4"
•
Frame Length: 23"
•
Saw Width: 20-1/4"
•
Front Axle Center Length: 7-1/2"
•
Rear Axle Center Length: 16-3/4"
•
Wheel Base Length: 12-5/8"
•
Blade Shaft Max. Height: 8"
•
Model No.: CC1113H, Engine Type: 13 HP Honda, P/N: 5800107,
Uncrated Wt.: 185 lbs.
* Add 40 lbs. for crated weight
Item #
Motor
RPM Blade Capacity
DPCC300M 3 Hp
3600
14”
Item #
Desc Max Depth of Cut (in.) Weight (lbs.)
DP03726 2.5 Hp
5
221
Item #
RPM Max Depth of Cut (in.)
DP04648
2,650
4
⁵⁄₈
Item #
DP46851
Item #
DP88915
