MILWAUKEE ELECTRIC TOOL CORP.
Clamp Meter for HVAC/R
The Milwaukee Clamp Meter for HVAC/R is a
heavy-duty True-RMS electrical current tester for
professional residential, commercial, and industrial
applications. The perfect tool for the professional
HVAC/R technician, the 2236-20 Clamp Meter provides
a wide 1.3” jaw opening to easily handle large
conductors, a thin jaw profile for access to tight spaces
and a high contrast white-on-black display for clearer
readings. In addition, the Milwaukee Clamp Meter for
HVAC/R was designed with embedded non-contact
voltage detection and an LED work light to increase end user
productivity.
•
Measures up to 600 amps AC, Large 1.30” jaw opening
•
Thin Jaw Profile for easier wire measurement in panels or in
bundles
•
Wide Voltage range to 600 AC/DC volts
•
True-RMS for accurate measurement in all applications
•
Built-In Voltage Detector and LED Work Light
•
Thermocouple (dual banana) input for contact temperature
measurement
•
600 uA DC for Flame Rectification
•
High Contrast, White on Black Display with Backlight for easy
reading
•
Rugged over-molding increases durability and user grip
•
Includes: Electrical Test Lead Set, Dual Banana Thermocouple,
(2) AA Batteries, Manual
MILWAUKEE ELECTRIC TOOL CORP.
Clamp Meter
The Milwaukee Clamp Meter is a heavy duty True-RMS
electrical current tester for professional residential,
commercial, and industrial applications. The perfect tool
for the professional electrician, the 2237-20 Clamp
Meter provides a wide 1.3” jaw opening to easily handle
large conductors, a thin jaw profile for access to tight
spaces and a high contrast white-on-black display for
clearer readings. In addition, the Milwaukee Clamp
Meter was designed with embedded non-contact
voltage detection and an LED work light to increase end
user productivity.
•
Measures up to 600 amps AC/DC, Large 1.30” jaw opening
•
Thin Jaw Profile for easier wire measurement in panels or in
bundles
•
Wide Voltage range to 600 AC/DC volts
•
True-RMS for accurate measurement in all applications
•
Built-In Voltage Detector and LED Work Light
•
Frequency Measurement
•
High Contrast, White on Black Display with Backlight for easy
reading
•
Rugged over-molding increases durability and user grip
•
CAT III 600V for increased safety
•
Includes: Electrical Test Lead Set, (2) AA Batteries, Manual
MILWAUKEE ELECTRIC TOOL CORP.
Laser Distance Meter
Alkaline Battery
•
Distance Range: 0.16’ (0.05m) to 197’ (60m)
•
Basic Accuracy: ± 0.059” (± 1.5mm)
•
Display Resolution: 000’ 00 in 1/8, 000.00’, 00.000
m
•
Arithmetic Functions
•
Includes: (2) AAA Batteries, Carrying Case,
Manual
MILWAUKEE ELECTRIC TOOL CORP.
160 X 120
Thermal Imager
M12™
The 2260-21 M12™ 160x120
Thermal Imager is faster, more
versatile and easier to use than any
other tool in its class. The M12 ™
160x120 Thermal Imager comes as a
complete kit including a professional
thermal imager with 160x120 pixel
resolution, a simple and powerful Thermal Imager Software to quickly
generate reports and leverages Milwaukee's M12™ battery system
for quick charging and easy field replacement.
•
Capture Thermal and Visual Images on each trigger pull for
enhanced reporting
•
Crisp, High Resolution 160x120 pixel Thermal Images for better
definition and clarity
•
Complete Report Software to easily analyze images
•
Broader Temperature Range (-10 to 350°C) to cover more
applications
•
5X Faster Battery charge over closest competitor
•
M12™ RED LITHIUM™ batteries allow for rapid field replacement
•
3.5” High Resolution LCD (640x480 pixel) for easier
troubleshooting
•
Built-In Visual Camera and Flashlight for improved analysis
•
Rugged Overmolding for increased durability and grip
•
Simple screen layout allows you to focus on getting the best
images
•
Raised corners protect the LCD and thermal engine if dropped
•
Hinged camera style lens cover is always attached, so is never lost
•
Knurled focus ring is easy to grip with arc flash PPE
•
All Thermal and Visual images use standard JPEG format for use
in any program
•
Media door seals the included 2GB SD card and USB connections
Features:
•
Temperature Range: 14 to 662°F (-10 to 350°C)
•
Display Type/Size: 3.5" Color LCD (640 x 480)
•
Battery Charge Time: 30 Minutes
•
Battery Life: > 4 Hours
•
Image Storage: 2GB SD Card. Upgradeable to 32GB
•
Temperature Accuracy: 2% or 2 deg C
•
Thermal Sensitivity: 0.1°C at 30°C
•
Minimum Focus Distance: 4 inches
Item #
Current
Range
Voltage
Range
Safety
Rating
Contact
Temp. Range
MI2236-20 600A AC 600V AC/DC CAT III 600V -40° to 752° F
Item # Current Range Voltage Range Safety Rating
MI2237-20 600A AC/DC 600V AC/DC CAT III 600V
Item #
MI2280-20
Item #
MI2260-21
