www.edgecs.com
64
Power Tools & Accessories
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
MILWAUKEE ELECTRIC TOOL CORP.
Heavy-Duty Polishers
•
11.0 Amps
•
0-1750 RPM
•
Single speed
•
Includes: Side handle, one 7"
rubber backing pad, disc nut and
nylon washer
MILWAUKEE ELECTRIC TOOL CORP.
Compact Band Saw
•
45% Lighter than Deep Cut - 9.5
Lbs compact light weight design
for cutting overhead and in tight
places
•
200-360 SFPM Variable Speed
Dial
•
3-1/4” Cut Capacity – cuts most
common materials for Electrician,
Plumber and Mechanical cutting applications, single pass cut on
3” copper, 3” angle iron, 2-1/2” conduit
•
Tool-Free Adjustable Material Shoe
•
LED Work Light
•
Blade Ejection System-Quickly change the blade
•
Drop Resistant Pulley Guard
•
Cast Aluminum Gear Case
MILWAUKEE ELECTRIC TOOL CORP.
Deep Cut Band Saw
The new Deep Cut Band Saws deliver 2X more durability, best-in-class power at 11 Amps, revolutionary cut
visibility and the industry’s largest cut capacity at 5" by 5"
•
Job Site Armor™ Technology: Proprietary composite material and crush zone barriers provide long lasting
rugged protection
•
All Metal Direct Drive: Delivers maximum tool life with all metal direct drive gearing system, while requiring
less servicing than a chain drive
•
Gear Protecting Clutch: Extends gear and motor life by absorbing high impact forces caused by blade lock-ups
•
Balanced Body Design: Allows tool to rest naturally and comfortably in users hands
•
LED Light: Illuminates work surface for increased accuracy and productivity
•
Tool-Free Locking Adjustable Shoe: Button actuated tool-free design allows user to quickly adjust from an extended shoe to no shoe in
seconds
•
Industry's Largest Cut Capacity: Versatility to cut up to 5” by 5” material in one pass and adjustable shoe allows for less tool rotation when
cutting material above 5”
MILWAUKEE ELECTRIC TOOL CORP.
Portable Drilling Machine Kit
Magnetic
Compact Model No. 4270-21
•
Powerful 1.1 max HP - 9.0 Amp
•
Milwaukee Motor - enables drilling with up to
1-1/2" diameter annular cutter and 2" depth of
cut (D.O.C.)
•
High strength magnet
•
Accepts 3/4" diameter shank annular cutters
•
1/2" dia. twist bit capacity with a 4-1/4" D.O.C
•
Two position tool-less feed handle can be easily mounted to either
side to allow for optimum drilling positions
•
Speed: 450 RPM
MILWAUKEE ELECTRIC TOOL CORP.
3/4" Motor for
Electromagnetic Drill Press
•
12.5 Amps maximum rating
•
Solid state electronic switching
•
Feedback speed control
•
Computer controlled reverse
•
Line Lock-Out prevents tools from operating should
voltage be restored to an interrupted line when switch
is locked in the "on" position
•
Motor/Magnet interlock
•
Automatic base/chip de-mag
•
Soft-start
Item #
MI5455
Item #
MI6242-6
Item # Description Voltage Amps
No Load
SFPM
Speed Control
Maximum Capacity
MI6232-20 Bare Tool
120 AC 11 30-380 Speed Dial w/ Variable Speed Trigger & CPT®
5” x 5”
MI6232-21
Kit
120 AC 11 30-380 Speed Dial w/ Variable Speed Trigger & CPT®
5” x 5”
MI6238-20 Bare Tool
120 AC/DC 11 300/380
On/Off Trigger
5” x 5”
MI6238-21
Kit
120 AC/DC 11 300/380
On/Off Trigger
5” x 5”
Item #
Includes
MI4270-21 Case
MI4720-20 Tool Only
Item #
MI4262-1
