Edge Construction Supply - page 73

Sales
Rental
Repair
Power Tools & Accessories
Boise, ID 208-377-0158
Eugene, OR 541-342-3641
Idaho Falls, ID 208-522-7082
Medford, OR 541-779-0187
73
MAKITA USA
16-5/16” Circular Saw
w/ Electric Brake
Large capacity blade cuts 6-1/4"
at 90° and 4-3/16" at 45°
Blade stabilizer for stable blade
rotation and superior cutting
performance
Large depth control lever for convenience and secure adjustments
Specifications:
Arbor: 1"
Max. Cutting Capacity: at 90° - 6-1/4", at 45° - 4-3/16"
No Load RPM: 2,200
AMPS: 15
MAKITA USA
12” Dual Slide
Compound Miter Saw
With Laser 15.0 Amps
Large cutting capacity for up to 8"
crown molding (nested), 6-1/2"
baseboard (vertical), and 15"
crosscut at 90°
Compact design with a patented
4-Steel Rail Sliding System further
increases rigidity to produce superior
cuts
Exclusive 5-1/2" tall dual sliding fence system features versatile
upper and lower fence adjustments for more precise miter and
bevel cuts
Miters 0°-52° left and 0°-60° right, with positive stops at 0°, 15°,
22.5°, 31.6° and 45° (left and right)
Bevels 0°-45° (left and right) with positive stops at 0°, 22.5°, 33.9°
and 45° (left and right)
MAKITA USA
10" Dual Slide
Compound Miter Saw
Built-in laser with micro fine
adjustments clearly indicates line
of cut; independent switch allows
laser to be seen independently of
blade rotation
Dual steel rails supported by
linear ball bearings ensure
stable, accurate cutting
Powerful, direct drive 15 AMP motor
Bevel positive stops at 33.9° and 45° left with 45° right
Long slide track and wide pivot angle allow cross cuts up to 4x12
material
Blade Diameter: 10"
Arbor: 5/8"
No Load RPM: 3,700
MAKITA USA
15 Amp Table Saw
Right extension table allows for greater
cutting capacity with the
capability to rip 4X8 sheets of plywood
Large cutting capacity (3-5/8" at 90º
and 2-1/2" at 45º)
Powerful 15 AMP motor delivers 4,800
RPM and has electric brake
Extended capacity with up to 25"
ripping
Dead-on cam-locking rip fence and
bevel locking handle for fast and easy adjustments
Specifications:
Blade Diameter: 10"
Arbor: 5/8"
Max. Cutting Capacity: 90° - 3-5/8", 45° - 2-1/2"
No Load RPM: 4,800
MAKITA USA
Reciprocating Saws
Anti-Vibration Technology (AVT)
gives unmatched comfort
Clutch protects the gears should
the blade bind adding life to the tool
Orbital action
Variable Speed Preset Dial:
6 different preset speeds to match the speed of the saw to the
application
Electronic Speed Control:
The blade can be inserted with one hand and ejected without
touching the hot blade
MAKITA USA
1/2” Electric Drill
Variable Speed, Reversible
Powerful 7 AMP motor for heavy duty
industrial performance
Large trigger switch is conveniently
located
Capacity: Steel 1/2"; Wood 1-1/2"
No Load RPM: 0 - 900
AMPS: 7.0
MAKITA USA
1/2" Angle Drill
2-Speed, Reversible
Sidewinder
Features:
2-Speed selector switch for high speed drilling (1,200 RPM) or low
speed (300 RPM) for large diameter
Torque limiter disengages motor should the bit bind (low speed
only)
Powerful 10 AMP motor for improved performance
Adjustable top handle with hex wrench storage for easy positioning
Item #
MA5402NA
Item #
MALS1216L
Item #
MALS1016L
Item #
MA2705X1
Item #
MAJR3070CT
Item #
MADP4000
Item #
MADA4031
