Telespar & Traffic
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
Telescoping Square
Tubing
Telespar
•
Holes on 1” center in telescoped
sections remain in perfect
alignment
•
Holes are 7/16” diameter
•
Hole patterns on 1, 2, or 3 sides
may be special ordered to meet
your specific needs
•
Sections without holes and Qwik-Punch® sections are available
•
Typically, available in 10, 12, and 14 gauge steel, standard lengths
are 20 and 24 feet
•
Edge can cut or quote other lengths to meet your project needs
•
Certificates of conformance and material origins will be available if
requested
•
Ask for drawings and specifications of our products to meet your
highway and DOT needs
•
One of the secrets of Telespar’s versatility is its ability to
telescope, smaller sizes fit smoothly and snugly into the next
larger size
•
Standard finish is pre-galvanized, inquire about Perma-Green or
plain finishes
Heavy-Duty Anchor
Telespar
HDA200 Series 2-1/2” Heavy-Duty Anchor
•
For permanent 2” square Telespar installation
•
Same as old part# UT25K12A3
HDA250 Series 3” Heavy-Duty Anchor
•
For permanent 2-1/2”x12ga. square Telespar
Installations
•
3” will also receive SB8-250300B-G slip base
•
Same as old part# UT30K12A3
Heavy-Duty Anchor
Winged
Telespar
TWA 200 Series 2-1/2” Heavy-Duty Winged Anchors
•
For permanent 2” square Telespar installations
TWA 250 Series 3” Heavy-Duty Winged Anchors
•
For permanent 2-1/2”x12 ga. square Telespar
installations
•
Will also receive SB8-250300B-G Slip Base
Item #
Tube Size
(in.)
Gauge
Length
(ft.)
Wt. (lbs.)
UT14F12PG 1
¹⁄₂
12
24
42.1
UT16D12PG 1
³⁄₄
14
24
41.3
UT16F12PG 1
³⁄₄
12
24
50.6
UT16F12PG-20’
1
³⁄₄
12
20
42.2
UT20D12PG-10’
2
14
10
19.9
UT20D12PG-12’
2
14
12
23.9
UT20D12PG
2
14
24
48.0
UT20F12PG
2
12
24
59.0
UT20F12PG-8’
2
12
8
19.6
UT20F12PG-10’
2
12
10
24.6
UT20F12PG-12’
2
12
29.5
UT20F12PG-14’
2
12
14
34.2
UT20F12PG-20’
2
12
20
49.2
UT21H12PG 2
³⁄₁₆
10
24
83.3
UT22F12PG 2
¹⁄₄
12
24
67.5
UT22F12PG-30”
2
¹⁄₄
12
2.5
7.0
UT24F12PG 2
¹⁄₂
12
24
75.9
UT24F12PG-10’
2
¹⁄₂
12
10
31.4
UT24H12PG 2
¹⁄₂
10
24
91.8
Qwik Punch
UT16D12-24-QP 1
³⁄₄
14
24
45.4
UT20D12-20-QP 2
14
20
43.6
UT20D12-24-QP 2
14
24
42.3
Item #
Length (in.)
Gauge
Wt. ea.
(lbs.)
2
¹⁄₂
”
UTHDA200-30-G 30
7
13.85
UTHDA200-36-G 36
7
16.63
UTHDA200-42-G 42
7
19.39
UTHDA200-48-G 48
7
22.17
3”
UTHDA250-18-G 18
7
10.05
UTHDA250-30-G 30
7
17.22
UTHDA250-36-G 36
7
20.6
UTHDA250-42-G 42
7
24.19
UTHDA250-48-G 48
7
27.48
Item #
Anchor Size
(in.)
Wt. Ea.
(lbs.)
2
¹⁄₂
”
UTTWA200-36-G 2
¹⁄₂
x36
28.71
UTTWA200-42-G 2
¹⁄₂
x42
31.15
UTTWA200-48-G 2
¹⁄₂
x48
34.55
3”
UTTWA250-36-G 3x36
35.00
UTTWA250-42-G 3x42
39.30
UTTWA250-48-G 3x48
43.08
