• Advanced patented non-directional sensing technology

• Superior sensitivity and functionality providing for accurate tracing and locating

• Ergonomic receiver with information-rich full-color graphical LCD

• Graphics and audible signal provide quick and easy to understand tracing feedback

• Traces concealed wiring, locates junction boxes, and finds breakers for live or open circuits

• Locates and identifies blown fuses

• Finds shorts and breaks in conductors

• Low pitch, high volume audible indicator

• User-selectable automatic or manual gain capability for fast, convenient use

• Power saving features promote extended battery life (Auto Power Off)

• Can be used on GFCI protected circuits

• Supports transmitter-to-receiver distances up to 4 miles for closed circuit tracing

• Does not affect sensitive electronic equipment on the circuit

• Auto backlight on receiver maximizes battery life

• Lifetime Limited Warranty

Operating Conditions:

• Temperature: 0 to +50 ºC (32 to 122 ºF)

• Altitude: 2000 m (6500’) maximum

• Pollution Degree: 2

• Indoor use only

Transmitter:

• Measurement Category: Category III, 750V

• Operating Voltage: 0-750 V AC/DC

• Live line LED indicates voltage above 12 VAC or 5 VDC

• Frequency: 15.15 kHz

• Low battery indicator

Receiver:

• Range from Receiver to item with Signal: Live Line Mode – up to 20 ft (6 m) from circuit, Open Line Mode – Up to 10 ft. (3 m) with a metallic connection to ground, 1 to 3 ft. (.3 to .9 m) with a capacitive ground reference
