• The solid steel deck platform has a slip-resistant surface

• Heavy-duty tubular steel guardrails maximize durability

• Telescopic end rail can be raised to accommodate large loads

• Lubrication-free, service-free pivot points

• Built-in lanyard attachment points

• The ergonomic joystick controller operates from the platform or the ground

• Low noise level allows operation in quiet work environments

• High angle steering provides excellent maneuverability

• Swing-out battery box and power module allow easy access to componentry

• Variable speed motor extends battery and motor life by using only the energy needed to do the required work

• On-board troubleshooting diagnostics notify the operators of possible fault conditions

Standard Features:

• 39 in. (1 m) roll-out platform extension

• Compact design

• Automatic 25 amp battery charger

• Proportional controls for lift and drive functions

• Multiple disc brakes provide smooth deceleration

• Drive speed interlock limits speed while elevated

• Emergency stop at both platform and ground controls

• Manual platform lowering valve

• Manual brake release

• Pothole guards

• Non-marking tires

• AC wiring to platform

• Tilt level sensor with an audible alarm

• Beeper horn

• Hour meter

Options and Accessories:

• Motion alarm

• Platform swing gate

• Maintenance-free battery

• Air line to platform

• Dual flashing beacon

Standards Compliance:

• ANSI/SIA A92.6

• CSA CAN3-B354.2-M82

• CE compliance option

• AS 1418.10

• Turning Radius Outside: 61”

• Power Source: 24V (4 6V 245AH Batteries)

• Drive Speed - Stowed: 0-2.5 mph;Drive Speed - Raised: 0-0.6 mph

• Extension Deck Lift Capacity: 250 lbs

• Length - Stowed: 72”

• Width: 30”

• Wheelbase: 52”

• Ground Clearance: 2[5/8]”

• Pothole Guards Deployed: 7/8”

• Platform Length - Outside: 64[3/8]”; Platform Width - Outside: 29 1/4”; Platform Length - Extended: 103[3/8]”

• Guard Height - ANSI/CSA: 39”; Guard Height - CE: 43[3/8]”

• Toeboard height: 6”

• Controls: Proportional

• Tires (Solid Rubber, Non-Marking): 12 x 4.5 x 8”

• Gradeability: 30%

• Drive: Dual front wheel

• Multiple Disc Brakes: Dual rear wheel

• Pothole otection: Standard
