RIDGE TOOL CO.
Tubing Cutters
Enclosed Feed Screw
•
Features an enclosed feed screw to
eliminate clogging and jamming,
grooved rolls for close-to-flare cuts,
and a fold-away reamer
•
Cuts copper, brass, and aluminum
tubing, and thin-wall conduit
•
Model 205 has all the features of the No. 150, plus a quick-acting
mechanism
RIDGE TOOL CO.
1/4 to 4-1/2”
Tubing Cutters
Quick Acting
I-Beam Construction
•
Models 151-156 feature a
quick-acting design, I-beam
construction, hardened wear
surfaces and thrust bearing slide
assemblies for smooth operation
•
All models now include an X-CEL
Knob and X-CEL Pin for quicker cutting and wheel replacement
•
These cutters are available in models for plastic pipe or metallic
tubing
•
Models 151 and 152 feature fold-away reamers
*Plastic models do not include a spare cutting wheel
** Nominal plastic pipe size
RIDGE TOOL CO.
Quick Acting CSST Cutter
•
Cuts corrugated gas tubing sizes 3/8"
- 1" diameter
•
Two sets of split-floating guide wheels,
located on the top and along the sides
of the cutter wheel, ride in the corruga-
tions to provide stable tracking, result-
ing in a high quality cut
•
Floating guide rollers also serve to hold the two pieces of pipe
together to ensure a complete and clean cut
•
Ergonomic knob provides a firmer grip to cut through tubing
quickly
•
Quick acting mechanism allowing the cutter to rapidly adjust from
3/8" - 1" diameter tubing.
•
Durable I-beam style frame
•
Weight: 1.1 lb.
RIDGE TOOL CO.
Cutter Wheels
Tubing
•
Replacement cutter wheels for
tubing cutters
74720:
Model Nos.: 131P/151P, 132P/152P, 153P, 205P denotes cutter wheel
furnished with original
33175:
Model Nos.: 30, 40, 134/154, 136/156 denotes alternate cutter wheel
Item # Model No.
Desc.
Cap. (in.)
RI31622
150
Enclosed Feed
Cutter
¹⁄₈
-1
¹⁄₈
RI31627
150
Above W/H-D
Wheel(s)
¹⁄₈
-1
¹⁄₈
RI33055
205
Ratcheting
Enclosed Feed
Cutter
¹⁄₄
-2
³⁄₈
Item #
Model
No.
Desc.
Std. Wheel Cap. (in.)
RI31632 151
Quick-Acting
Cutter
E–3469
¹⁄₄
-1
⁵⁄₈
RI31637 151-P Above w/Wheel
for Plastic
E-2155
¹⁄₈
-1
¹⁄₄
**
RI31642 152
Quick-Acting
Cutter
E–3469
¹⁄₄
-2
⁵⁄₈
RI31647 152-P Above w/Wheel
for Plastic
E-2155
¹⁄₄
-2**
RI36597 153
Quick-Acting
Cutter
E–3469 1
¹⁄₄
-3
¹⁄₂
RI36592 153-P Above w/Wheel
for Plastic*
E-2155
1-3**
RI31652 154
Quick-Acting
Cutter
E–2558 1
⁷⁄₈
-4
¹⁄₂
RI31657 154-P Above w/Wheel
for Plastic*
E-2156 1
¹⁄₂
-4**
RI31662 156
Quick-Acting
Cutter
E-2558 4-6
⁵⁄₈
Item #
RI32078
Item # Model No. Std. Pk.
Blade Exp.
Application
RI33160 F-158
Aluminum &
Copper
RI33165 E-1240
Steel/Stainless
Steel
RI33170 E-2558
Aluminum &
Copper
RI33175 E-2191
6
.292
Steel Tubing
RI33180 E-5299
6
.412
PVC, ABS,
Std. Wall
RI33185 E-3469
Aluminum &
Copper
RI33190 E-4546
Steel/Stainless
Steel
RI33195 E-5272
6
.290
PVC, ABS,
Std. Wall
RI33200 E-1740
Soft Flexible
Plastic
RI33205 E-2990
1
.112
Steel,
Aluminum&
Copper
RI74720 E-2155
1
.286
PE, PB, PP,
Std. &
Heavy Wall
RI74730 E-2156
PE, PB, PP, STD
& Hvy Wall
