www.edgecs.com
154
Mechanical & Plumbing Tools
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
RIDGE TOOL CO.
115V Electric Solder Gun
Model RT-175 Professional
•
For 1/4” to 3” tube (soft soldering)
•
Flameless soldering - safe,
easy-to-use
•
Twelve feet of cable
•
Fully contained in metal carrying case
RIDGE TOOL CO.
Pipe Freeze Tool Kit
Model SF-2500 - SuperFreeze™
•
SuperFreeze® Pipe Freezing Tool
Avoids the Cost and Inconvenience
of a System Shutdown and Purge.
•
The SuperFreeze Pipe Freezer is an
easy-to-use pipe freezing unit that
allows the contractor to keep water
systems operating while making
repairs. The Ridgid SF-2500 is a
mini-refrigeration unit that circulates self-contained refrigerant to
its aluminum freeze heads. This forms an ice plug in as little as 6
minutes in 1/2" copper tube and can be used with up to 2-1/2" tube
or 2" pipe. Once the pipe is plugged, repairs can be made while
the ice plug is maintained by the unit. Now includes a bottle of
specially formulated freeze gel to speed freezing. Apply the gel to
freeze heads before placing on pipe.
•
Approved by UL to CSA and UL standards
•
Capacity: Copper Tube: 1/2" - 21/2”; Steel Pipe: 1/2" - 2"
•
Compressor: 115V, 60 Hz, 4.3A
•
Refrigerant: R-507 (14.2 oz. charge)
•
Hose Length: 8.5 ft. (17 ft. span)
•
Dimensions: L = 21" W = 10.5" H = 13"
RIDGE TOOL CO.
Pipe Thawers
For fast thawing of frozen metal
pipes 1/2" through 1-1/2" (12-36
mm).
KT-200 pipe thawing unit provides
continuous heating to quickly thaw 1/2" to 1-1/2" frozen metal pipes.
Simply attach the clamps to the metal pipe on each side of the frozen
section and the pipe is thawed within minutes.
•
KT-200 can be used on 4' to 150' lengths of pipe; the KT-200'S
amp meter allows the user to select the proper output level for
maximum current draw and minimum thawing time
•
Powerful: Units operate on a standard 115V, 15 amp outlet; the
KT-200 produces 250-400 amps of thawing power
RIDGE TOOL CO.
Press Tool
Model RP 210-B
The Model RP 210-B is a fast and reliable
way to join copper, stainless steel and
PEX fittings. It is 2 inches shorter and
25% lighter than our previous compact
tool for more pressing with less fatigue.
It’s 270° rotating swivel jaw helps users
get into tight places. With a 5,400
pounds hydraulic ram output, the Model
210-B has more capacity than any compact press tool available. As
part of this new design, the Model 210-B service interval has been
extended to 32,000 cycles.
Specifications:
•
Capacity: 1/2” to 1-1/4” for copper and stainless, 3/8” to 1-1/2” for
PEX
•
Compatible with all Ridgid® compact series pressing attachments
•
270° barrel/jaw swivel
•
Battery: 18V Li-Ion, 1.1 Ah
•
Hydraulic Ram Output: 5,400 lbs.
•
Weight: 6.4 lbs. with battery
•
Operating Temperature Range: 15°F - 122°F
•
Approximate Cycle Time: 5 seconds
•
Standard Kit Includes: RP 210-B Press Tool, 2 Batteries, Battery
Charger and Carrying Case
RIDGE TOOL CO.
Corded Press Tool
Model RP 340
•
270° Barrel/Jaw Swivel
•
Hydraulic Ram Output: 7,200 lbs.
(32kN)
•
Weight: 8.5 lbs. (w/Battery), 9.5
lbs. (w/AC Power Adapter)
•
Approximate Cycle Time: 4
seconds
•
LED-light For Continued
Operations In No or Low-light
Environments
•
Kit Includes: Pro Press Jaws 1/2”-2”, AC Power Adapter and
Carrying Case
Item #
RI62862
Item #
RI68967
Item # Model No.
Desc.
RI62747
KT-200 Pipe Thawer W/2-25 (ft.)
¹⁄₁₀
Cables
Item #
Desc.
RI31028 RP 210-B Battery Press Tool Kit
w/ProPress Jaws (
¹⁄₂
” - 1
¹⁄₄
”)
Item #
RI43373
Make a connection
at the EDGE
