www.edgecs.com
156
Mechanical & Plumbing Tools
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
RIDGE TOOL CO.
Inspection camera
micro CA-100
Inspection camera allows you to
perform detailed visual inspections in
hard-to-reach areas.
•
Comfortable pistol-grip design,
one-hand controls, and large screen
make it easy to detect and diagnose
the unreachable
•
Comes standard with a rugged 3/4 inch anodized aluminum
camera head with 4 super bright LEDs
•
Easily rotate the active image counter-clockwise to see in any
situation
•
Display (320x240 Resolution): 3.5" Color LCD
•
Cable Reach: 3' (Expandable to 30' w/ optional extensions)
•
Video Output: 3' RCA Cable (included)
•
Attachments: Mirror, Hook & Magnet
•
Weight: 5.5 lbs
RIDGE TOOL CO.
0.26”/6mm Diameter
Imager Head Assembly
•
Over 50% smaller than the standard
camera head
•
Enables detailed inspection in very
confined spaces
•
Bright LED lighting provides clear
images
•
Sleek aluminum construction withstands demanding applications
•
Compatible with CA-100, CA-300 and universal extensions
RIDGE TOOL CO.
Compact Video
Inspection System
Seesnake®
The SeeSnake Compact System
offers fast setup for quick
inspections. Its ultra portability
makes this system an excellent
complement to your SeeSnake Plus.
Standard Equipment:
Power Source:
•
Battery port for use with optional 18V battery
•
AC/DC operation
MINIPak Monitor System:
•
High-resolution monitor
•
Push button controls for sonde, power, lights, flipscreen and
zeroing the counter
•
Splash-resistant case with built in sunshade
•
Video In/Out jack
Camera System:
•
Scratch-resistant, debris-shedding, flush-mounted sapphire lens
•
Integrated transmitter
•
Durable stainless steel camera head assembly and tapered spring
assembly
Reel:
•
100’ of push cable
•
Debris-capturing, rotating drum with mercury-free slip ring
•
Counter to display distance on monitor in feet and inches
RIDGE TOOL CO.
Utility Line Locator
SeekTech SR-20
•
Proximity Signal Minimizes depth over
target and maximizes relative signal
strength to guide you closer to the target
independent of the current flow
•
Mapping Display Virtually maps the utility
to help guide you down the line. Shows
signal distortion and line turns in real time
•
Continual Depth Increase productivity by
showing depth changes in real time
•
Guidance Arrows Guides the operator to target line by minimizing
signal gradient
•
Active Line Trace Frequencies: 128Hz, 1kHz, 8kHz, 33kHz
•
Sound Frequencies: 16Hz, 512Hz, 33kHz
•
Passive Power Trace: 50Hz, 60Hz
•
Passive Radio Trace: <4kHz, 4kHz-15kHz, 15kHz-38kHz
Item #
Description
RI36738 micro CA-100 Inspection Camera
RI37103
17mm Replacement Imager
RI37108
3´ Cable Universal Extension
RI37113
6´ Cable Universal Extension
Item #
Description
RI37098 1m Length x 6mm Diameter Replacement Imager
RI37093 4m Length x 6mm Diameter Replacement Imager
Item #
Desc.
RI32903 Color Compact System w/Battery & Charger,
115V
Item #
RI21893
See where no one has
seen before with Ridgid
