RIDGE TOOL CO.
Power Threading
Machine Accessories
Machine Stand Adapter
Bracket
Model 535
RIDGE TOOL CO.
Threading Machine
1/2” to 1-1/2” NPT
Model No. 1215
•
Through die head oiling
Standard Equipment:
•
1 - No. 811A Quick Opening Die
Head
•
1 - Set 1/2”-3/4” Universal alloy NPT dies
•
1 - Set 1” - 1-1/2” Universal alloy NPT dies
•
1 - No. 344 five fluted reamer 1/4” - 1-1/2”
•
1 - No. 732 Cutter with cutter wheel
•
1 - Gallon Nu-Clear oil
RIDGE TOOL CO.
Power Threading Unit
With Folding Wheel Stand
No. 300 Compact Kit
Model 300 compact threading machine
capacity:
•
Pipe: 1/8”-2”
•
Bolt: 1/4”-2”
•
Lightweight, portable design
•
Fast transport and set-up
•
Self-contained oil system
•
Hammer-type chuck with replaceable, rocker-action jaw inserts
Standard Equipment:
•
Model 300 compact threading machine
•
1-No. 811A quick-opening die head
•
1-No. 344 reamer
•
1-No. 360 cutter with E-1032 cutter wheel
•
1 Set 1/2”-3/4” alloy universal dies
•
1 Set 1”-2” alloy universal dies
•
1 gallon Nu-Clear threading cutting oil
•
Includes Model 250 folding wheel stand
RIDGE TOOL CO.
Power Threading Unit
1/2 - 4" NPT, 120V 60Hz
Model 1224
The 1224 threads a wide range of pipe
including black, galvanized and plastic
coated pipe, together with stainless steel,
IMC and heavy-wall conduit, as well as rod
up to 30 Rockwell C.
Capacity:
•
Pipe: 1/4”-4”; 4”-6” with 161 geared
threader; Bolt: 1/4”-2”
Features:
•
Threads 1/4”-2” pipe and 2-1/2”; 1/4” - 2” universal die head;
2-1/2” - 4” receding die heads allows cutting of tapered or straight
NPT/NPSM; constant and proper lubrication of dies and
workpiece with through-head oiling
Technical specifications:
•
1 No. 714 (914) 2-1/2” - 4” receding self-opening die head
•
1 No. 711 (911) 1/4” - 2” universal self-opening die head
•
1 set 1/2” - 3/4” universal alloy dies
•
1 set 1” - 2” universal alloy dies
•
1 set 2-1/2” - 4” 1224 high speed dies
•
1 gallon Nu-Clear oil
•
3 hex keys; 1 spare F-229 cutter wheel
•
1-3/4” combination wrench
•
1 tool box
•
1 No. 744 reamer
•
1 No. 764 cutter
RIDGE TOOL CO.
Die Heads
For Model No. 1224
Note: Die heads do not include dies.
All die heads are through-head
oiling.
RIDGE TOOL CO.
Pipe Die Set
For Model 1224 Threader
NPT High Speed
•
For Model 1224 Threader
Item #
Desc.
RI58007 Machine stand adaptor bracket for
535's built before 1996
Item #
RI61142
Item #
RI67182
Item #
RI26092
Item # Model No.
Desc.
Capacity (in.)
RI26132 711
Universal Self-Opening
R.H., NPT
¹⁄₄
- 2
RI26152 714 Receding Self-Opening
R.H., NPT
2
¹⁄₂
- 4
Item #
Desc.
Capacity (in.)
RI26192
1224 H.S. Dies NPT
2
¹⁄₂
- 4
RI33057 1224 H.S. Dies NPT for Stainless Steel
2
¹⁄₂
- 4
