165
REED MFG
PE Squeeze-Off Tools
•
Reed offers the best designed
tools for stopping flow in PE pipe
with capacities of 1/2” to 8”
•
Sliding bar handles make work in
tight places easier and increase
leverage for tightening
•
Other features include fine-pitched
thread to allow for a controlled,
low-effort squeeze; greased fittings
to make operation easier and
extend life; and aluminum parts to make tools lighter for easier
handling
•
Aluminum castings also withstand varied climate and soil
conditions
•
All tools use positive stops to prevent damage caused by
over-clamping
•
PES1 models feature a stationary bottom bar
•
The PES2 and PES4 series have an affixed bottom bar, which
swings open to fit over any location on the pipe
•
RDPES2PC160 features CTS-specialized stops for Pressure
Class 160 tube
•
PES2-2 models have a new double-bar design with two squeeze
points in a row which provide better shut-off and extra protection
against leaks, right in one tool
•
Reed’s PES8s are available in manual or hydraulic models and
also feature the new double-bar design - RDPES8M requires
manual operation, uses two stops, and allows a dozen different
pipe/SDR combinations - RDPES8H utilizes a hydraulic pump and
offers a pressure gauge and saddle clamps
•
An optional Flow Control Valve Kit is available to control release of
the upper jay to reduce risk of static build-up
•
Attention Utility Contractors: PES2 models can be used on both
CTS and IPS PE pipe by simply changing the safety stops
•
*RDPES2PC160 Rated for working pressure to 160 psi
REED MFG
Valve Wheel Wrenches
•
Reed valve wheel wrenches grip
the rims of hand valve wheels
securely and provide leverage for
opening and closing
•
Choose a wrench based on the
hook opening
•
RDVKVW fits standard valve nuts and is made of heavy-duty
mechanical steel tubing
•
RDVWALP1 and RDVWALP2 offer a low-sparking benefit due to
aluminum-magnesium alloy construction
ROTHENBERGER
Ropower 50R Compact
Threading Machine
The Ropower 50R uses
Ridgid®-compatible dies with the new
quickchange ball detent feature. While
other manufacturers’ Ridgid® style dies
may be used in the 50R die head (56265),
only Rothenberger’s dies snap into
position.
•
Machine slightly angled: Reduced oil consumption, oil moistening
in pipe interior is avoided
•
NPT dia.: 1/4”-2” capacity
Includes:
•
Automatic die head with NPT Alloy dies 1/2”-2”, 1/2”-3/4” NPT dies
(89162), 1”-2” NPT dies (89163)
Item #
Capacity
(in.)
Pipe/SDR
Stops Length (in.)
RDPES1IPS
¹⁄₂
-1
3
11
RDPES1CTS
¹⁄₂
-1
3
11
RDPES2IPS
¹⁄₂
-2
6
12
RDPES2CTS
¹⁄₂
-2
6
12
RDPES2PC160
¹⁄₂
-2
6
12
RDPES4
2-4
7
20
RDPES8M 3-8
12
28
RDPES8H
3-8
12
28
RDPES2-2IPS
¹⁄₂
-2
6
12
RDPES2-2CTS
¹⁄₂
-2
6
12
Item #
Style
Material
Hook
Opening (in.)
Length
(in.)
RDVKVW 2” Square
Nut
mechanical
steel tubing
2” Square 21
RDVW0 Double-end forged steel
¹⁄₂
&
²¹⁄₃₂
8
RDVW1 Single-end forged steel
1
15
RDVW2 Single-end forged steel
1
⁵⁄₁₆
22
RDVW3 Single-end forged steel
2
27
RDVW10 Double-end forged steel
¹¹⁄₁₆
& 1
10
RDVWALP1 Single-end aluminum 1
³⁄₈
14
RDVWALP2 Single-end aluminum 1
³⁄₄
18
Item #
Desc.
RO63005
Ropower 50 R
Accessories
RO56051 Wheeled Folding Stand
RO04510R
Cutter Wheel
