REED MFG
Pipe Cutter
C Shape
Easy-to-grip cutter easily snaps on to copper tubing for a quick, clean cut. Just turn the cutter in the direction of the
arrow and the cut will be complete in seconds. Compact c-shape means no handle swing space is required. The
spring-loaded cutter wheel self-feeds on Type K, L, and M copper and CTS CPVC with consistent pressure as the tool
is turned around the tubing. Each cutter fits just one popular size of copper tubing.
REED MFG
Hinged Cutters™
•
Four wheels cut steel, stainless steel, cast and
ductile iron with only 90° to 110° handle swing
•
Only 4" clearance required around pipe
•
Strong guide fingers ensure perfect alignment for
square cuts
•
A closed 360° frame forces all energy into cutting
the pipe for maximum efficiency
•
This is the only hinged cutter that tracks every time
and the only one recommended for ductile iron,
steel, and stainless steel to Schedule 100
•
Note: S= comes with wheels for steel; I= for cast
and ductile iron; X= for schedule 80 steel; XX= for schedule 100
steel.
REED MFG
Tripod Chain Vise
Manufactured with the heaviest gauge
steel, overlapping hinges, and the best
adjustable tray clamp, not a set screw, to
keep the lower tray assembly and entire
portable workbench tight – even after many
hours of use! The heavy-duty design
permits use with pipe up to 6” diameter.
The exclusive double-faced jaws provide a
second set of jaws with options available
for both metal and plastic pipe (R450P).
REED MFG
Field Pipe Vise
•
Field Pipe Vise holds pipe up to
20” diameter
•
More pipe capacity than other
Reed vises; 2,000 lb. vise
capacity
•
Super choice for pre-trench work
and above ground cuts
•
Excellent flexibility achieved in
height and length of vise
appropriate to application as
customer may cut own pipe for legs and backbone
Item #
Pipe Capacity (in.)
Application
RDTC50SLR
¹⁄₂
CTS CPVC, Hard M copper, L copper, and soft K copper
RDTC50SL
¹⁄₂
CTS CPVC, Hard M copper, L copper
RDTC72SLR
³⁄₄
CTS CPVC, Hard M copper, L copper, and soft K copper
RDTC75SL
³⁄₄
CTS CPVC, Hard M copper, L copper
RDTC1SLR
1
CTS CPVC, Hard M copper, L copper, and soft K copper
RDTC1SL
1
CTS CPVC, Hard M copper, L copper
Item # Nom. Pipe Capacity (in.) Length (in.)
RDH21/2S
1 - 2
¹⁄₂
17
RDH21/2I
1 - 2
¹⁄₂
17
RDH21/2X
1 - 2
¹⁄₂
17
RDH4S
2 - 4
22
RDH4I
2 - 4
22
RDH4X
2 - 4
22
RDH6S
4 - 6
28
RDH6I
4 - 6
28
RDH6X
4 - 6
28
RDH8S
6 - 8
32
RDH8I
6 - 8
32
RDH8X
6 - 8
32
RDH8XX
6 - 8
32
RDH12S
8 - 12
34
RDH12I
8 - 12
34
RDH12X
8 - 12
34
RDH12XX
8 - 12
34
Item # Pipe Capacity (in.)
RD450+
¹⁄₈
-6
Item # Pipe Capacity (in.-Nom.)
RDFPV20
2-20
