163
REED MFG
Universal Pipe Cutters
•
Lightweight, easy-to-use Universal
Pipe Cutters (UPC) are available
to cut 6” - 48” (150-1300 mm)
outside diameter ductile iron, cast
iron, clay, concrete, steel, PVC, or
PE pipe
•
The cutters are pneumatic powered
•
The lower cost RDUPC616A uses the same motor as the others,
but does not need connecting frames
•
The RDUPC616 is shipped in a steel toolbox with a three-gallon,
formed-steel water tank
•
The RDUPC636A and RDUPC648A come in a steel toolbox with a
seven-gallon, stainless steel water tank and cart
•
Must order required blades separately
REED MFG
Universal
Pipe Cutter Blades
REED MFG
Electric Hydrostatic
Test Pumps
•
Designed for pressure testing water
systems such as water meters,
plumbing lines, pressure vessels,
solar systems and sprinkler
systems, in both residential and
commercial buildings. A standard
110V outlet is required and the
electric motor is UL certified. The
output pressure is easily adjusted simply by turning a knob and
watching the attached gauge. A built-in bypass allows for
automatic water recirculation once the set pressure is reached.
When the pump is turned off, it can be easily disconnected from
the test system and taken elsewhere or stored away. The
hose-to-pump connection features a quick disconnect with built-in
check valve, which allows for convenient setup and portability.
Each pump includes a high pressure EHTPOUTHOSE for filling
the system.
REED MFG
Hydrostatic Test Pumps
Designed to test water meters, plumbing lines,
pressure vessels, solar systems and sprinkler
systems, in both residential and commercial
buildings. The test pumps are portable and can
be used to test modest irrigation lines. Pump
operation requires the user to first fill the
system that needs to be tested. Next, the user
raises the system pressure by actuating the test pump handle.
Finally, the user closes the pump’s ball valve at the desired pressure.
The user determines leakage based on dropping pressure as
indicated by the hydrostatic test pump’s pressure gauge. The pump
has a relief valve that reduces the likelihood of over-pressuring the
system. Hoses are sold separately.
REED MFG
Manhole Hooks
High Carbon Steel
•
Hooks are forged of 5/8” hex high
carbon steel
•
Handle fits large hand
•
RDMH30 has rotated handle and
rocker head to more easily enter
notch in stubborn covers
•
Points are 1/2” wide for cover
openings
Item #
Pipe Dia. (Inches-Nom.)
RDUPC616A
6-16
RDUPC636A
6-36
RDUPC648A
6-48
Item #
Desc.
Pipe
Dia. (in.)
Pipe Material
RDUPCARB4 4” Blades cut
up to
²³⁄₃₂
”
wall
thickness
6
PVC
RDUPBEVEL Available by
special order,
minimum
order applies
PVC
RDUPCARB6 6” Blades cut
up to 1
²³⁄₃₂
”
wall
thickness
8 - 48
PVC
RDUPCSTEEL4 4” Blades cut
up to
²³⁄₃₂
”
wall
thickness
6-8
Steel, PE
RDUPCSTEEL6 6” Blades cut
up to 1
²³⁄₃₂
”
wall
thickness
8-48
Steel, PE
RDUPDIA6C 6” Blades cut
up to 1
²³⁄₃₂
”
wall
thickness
8-48 Cast Iron, Pit
Cast, Ductile Iron
Clay, Concrete
RDUPDIA4C 4” Blades cut
up to
²³⁄₃₂
”
wall
thickness
6
Cast Iron, Pit
Cast, Ductile Iron
Clay, Concrete
Item #
Capacity
RDEHTP500 500 PSI
RDEHTP500C 500 PSI
Item #
Capacity (psi.)
RDHTP300
300
RDHTP1000
1000
Item # Handle To Hook Relationship Length (in.)
RDMH26
Same Plane
26
RDMH30
Hook 90° To Handle
30
RDMH36
Same Plane
36
