TUTHILL
Digital Display
Flow Meter
Fill-Rite
Fill-Rite Positive Displacement -
Nutating Disc meter is ideal for end of
hose use, in line or mounted to one of
our Rotary Vane or 400B Series
Diaphragm Pumps. It is able to store
and display the current flow amount
(total) or the cumulative flow amount
(totalizer) in any of six user-specified units.
Features:
•
2-20gpm flow
•
Pressures to 125psi max
•
Glass-filled Polypropylene housing
•
Fluorocarbon seals
•
1"FNPT ports
•
-10°F-130°F Temperature range
•
360° positioning display
•
Quick, one step calibration
•
Waterproof, corrosion-resistant
•
20 stored calibration factor settings
•
Two alkaline AA batteries included
TUTHILL
115V AC High Flow Pump
1" Hi Flow Automatic Nozzle, 901 Meter
•
Up to 23 GPM open flow / 19
GPM at end of nozzle
•
1/3 HP Motor
•
UL/cUL Listed Pump and Motor
•
Heavy Duty Cast Iron Construc-
tion
•
Diesel/Gasoline/Kerosene/E15/
BD up to BD20
•
2 year warranty
•
2" Threaded base for tank
mounting
•
Iron Rotor with Carbon Rotary
Vanes
•
Self Priming
•
Check Valve, Pressure Relief Valve, and strainer included
•
1" x 18' UL Listed Hose
•
901 Mechanical Meter
•
Ultra High Flow Nozzle
TUTHILL
115/230V High Flow AC Pump
3/4 HP UL Motor, 900D Meter, 1"x18' Hose,
1" Ultra High Flow Automatic Nozzle
•
35 GPM/132 LPM 27 GPM/102 LPM
at end of Nozzle
•
3/4 HP Motor
•
UL/cUL Listed Pump and Motor
•
Heavy Duty Cast Iron Construction
•
2 Year Warranty
•
2" Threaded Bung for Tank Openings
•
Iron Rotor with Carbon Rotary Vanes
•
Self Priming
•
Check Valve, Pressure Relief
•
900D Meter
•
1" Ultra High Flow Nozzle
•
1" x 18' foot hose with Static Wire
TUTHILL
Air Operated Diaphragm
•
Max Flowrate (flooded suction): 17.5 gpm
(79.56 lpm)
•
Max Inlet Pressure: 100 psi (7bar)
•
Max Outlet Pressure: 100 psi (7 bar)
•
Air Consumption @ 40psi: 0.65 cfm/gal
•
Displacement/Cycle @ 100psi: 0.036 gal
(0.14L)
•
Max Particle Size: 3/32” dia (2.4mm)
•
Noise Level @ 70psi: 75.0 db(A) at 60 cpm
•
Ratio: 1:1
•
Inlet/Outlet: ¾” / ¾" NPT
•
Air Inlet: º” NPT
•
Air Exhaust: 1/8” NPT
•
Air Inlet Pressure Range: 2-100 psi (0.14-7 bar)
•
Max Material Inlet Pressure: 10 psi (0.69 bar)
•
Fluid Outlet Pressure Range: 2-100 psi (0.14-7 bar)
•
Max Pump Speed: 450 cpm
•
Max Suction Lift (water w/ Hytrel Balls: 14 ft (4.27 m
TUTHILL
Hydrosorb Filter Kit
Hydrosorb Filters (water absorbing) help to
contain water or microbial contamination
•
Includes filter head, filter canister, 3/4" x 5"
galvanized nipple
•
70 l/min
•
Suitable for Diesel or Gasoline
Item #
FI820
Item #
FIFR711VA
Item #
FIFR319VB
Item #
Fluid Compatibility
FISP100-05N-CD-HHH Transmission Fluid, Anti
Freeze, Waste Oil, New Oil
FISP100-050N-PP-SSS Diesel Exhaust Fluid,
Ag Chemicals
FISP100-05N-PP-TTP Windshield Wiper Fluid,
Ag Chemicals
Item #
FI1210KTF7019
