WEATHER GUARD® TRUCK & VAN EQUIPMENT
Steel Ladder Rack
WEATHER GUARD® Truck Equipment
•
Load capacity rating is 1000 lbs.
Capacity is increased to 1500
lbs. when using the Accessory
Screen
•
Includes 4 legs, 3 cross mem-
bers and 2 side rails
•
Ford Super Cab Super Duty, GM,
Dodge and Ford F-150 extended
cab require separate purchase of
Model 1247 Airfoil
•
Adjustable leg socket allows
easy positioning of the leg for
proper fit to truck bed
•
Removable pin allows you to quickly take off the rear cross
member for loading large materials
•
Tie down bracket can be bolted wherever you wish
DELTA CONSOLIDATED INDUSTRIES
Vehicle Ladder Racks
PRO III™
•
Swaged joints and fully gus-
seted crossbars for superior
load capacity
•
Yellow zinc dichromate undercoat and marine-grade polyester
epoxy power paint finish has superior resistance to corrosion and
abrasion
•
Optional 4th crossbar bolts on side channels where needed to
support long, heavy loads
•
Optional “no drill” clamp-on mounts eliminate drilling holes to
mount the rack
WEATHER GUARD® TRUCK & VAN EQUIPMENT
Standard Underbed Box
WEATHER GUARD®
Truck Equipment
•
Large open stainless steel D handle is
easy to grab and operate
•
Versatile 180° drop down door
•
Three point latching system creates a positive closure on three
sides of the door, making it secure and water resistant
•
Finish: White Steel*
WEATHER GUARD® TRUCK & VAN EQUIPMENT
Aluminum Underbed Boxes
WEATHER GUARD® Truck Equipment
•
Box and door are made of heavy
.100 thick diamond-plate
aluminum
•
Aluminum door features a
welded-on reinforcing channel to
make the door more rigid and
assure a weather-tight seal
•
Brushed stainless steel paddle
handle for extra life and durability
•
Recessed door to allow for full
swing-down position with cables disconnected
•
ARMOR TUF® powder coating
•
Finish: Aluminum Diamond Plate*
WEATHER GUARD® TRUCK & VAN EQUIPMENT
All Purpose Van Racks
WEATHER GUARD®
Van Solutions
•
Powder Coated heavy duty steel
rack for full-size vans
•
Additional cross members can be
added for longer materials and
ladders
•
Available finishes include durable bright white, black or clear coat
•
Velcro straps assist in securing your ladder for transport
Item #
Type of Vehicle
Length
(in.)
ShipWeight
(lbs.)
KN1245 Full Size Pickup-Short Bed 133
¹⁄₂
159
KN1275 Full Size Pickup-Long Bed 149
¹⁄₂
171
Item #
Desc.
DBL80000 Full Size Fully Adjustable Ladder Rack
Item #
Dimensions
(HxWxL in.)
Weight
(lbs.)
Cubic
ft.
Door Opening
H x W (in.)
KN530-3-01 18
¹⁄₈
x18
¹⁄₄
x30
¹⁄₈
70 5.6 14
¹⁄₂
X28
¹⁄₂
KN536-3-01 18
¹⁄₈
x18
¹⁄₄
x36
⁵⁄₈
82 6.7 14
¹⁄₂
X34
³⁄₄
* Also available in black steel finish
Item #
Dimensions
(HxWxL in.)
Weight
(lbs.)
Cubic
ft.
Door Opening
H x W (in.)
KN631 18x18x30
¹⁄₈
42 5.4 13
¹⁄₂
x25
¹⁄₄
KN636 18x18x36
⁵⁄₈
47 6.5 13
¹⁄₂
x31
³⁄₄
* Also available in black aluminum diamond plate
Item #
Number of
Cross
Members
Height
(in.)
Width
(in.)
Length
(in.)
Ship Weight
(lbs.)
KN205-3
2
16
8
70
¹⁄₂
42
KN216-3
3
16
8
70
¹⁄₂
63
Don’t forget
ratchet straps
