CONSTRUCTION ELECTRICAL PRODUCTS
480 Volt 3 Phase
Power Station
Transformer Based
These heavy-duty 3 phase power distribution carts are designed to breakdown 3 phase
120/208V power into 208V 3 phase, 250V single phase and/or 125V single-phase power. The power supply input may be a
direct wire feed, 100A pin and sleeve, or cam type devices. Either a large generator or another large power source may
power them. These panels may be designed to act as the feeder for the smaller spider type boxes or wired for powering
large equipment. The cart is made of heavy gauge tube steel and provides an easy means of transportation as well as
protection for the enclosure. The enclosure is custom built from 16 gauge sheet metal. 100A, 200A, 400A and special
configurations are available upon request.
•
Heavy duty cart
•
Clear breaker panel window
•
Easily stackable
•
GFCI protection available
•
3R and 4X available
•
Stainless steel 16ga. enclosure
•
UL Listed
CONSTRUCTION ELECTRICAL PRODUCTS
3 Phase Distribution Panels
These heavy-duty 3 phase power distribution carts are designed to breakdown 3 phase 120/208V power into 208V 3
phase, 250V single phase and/or 125V single-phase power. The power supply input may be a direct wire feed, 100A
pin and sleeve, or cam type devices. Either a large generator or another large power source may power them. These
panels may be designed to act as the feeder for the smaller spider type boxes or wired for powering large equipment.
The cart is made of heavy gauge tube steel and provides an easy means of transportation as well as protection for the
enclosure. The enclosure is custom built from 16 gauge sheet metal. 100A, 200A, 400A and special configurations are
available upon request.
•
Heavy duty cart
•
Clear breaker panel window
•
Easily stackable
•
GFCI protection available
•
3R and 4X available
•
Stainless steel 16ga. enclosure
•
UL Listed
Item #
Transformer KVA Sizes
Primary Disconnect
CEP6214PDC15
15KVA
30A
CEP6210PDC30
30KVA
60A
CEP6212PDC30
30KVA
60A
CEP6220PDC45
45KVA
60A
CEP6220PDC75
75KVA
90A
CEP6221PDC75
75KVA
90A
CEP6240PDC150
150KVA
200A
CEP6241PDS150
150KVA
200A
Item #
Main Breaker Rating/Input Type
Output Receptacles (Qty.)/Nema#/Amp-Volt Rating
CEP6210DC 100 Amp 120/280V Direct Wire
(10) 5-20R 20 Amp 125V Straight GFCI, (2) L6-30R 30 Amp 250 V Twist
CEP6211DC 100 Amp 120/280V Direct Wire (4) L21-20R 20 Amp 120/208V Twist, (2) 5-20R 20 Amp 125V Straight GFCI
CEP6220CC 200 Amp 120/280V Cam Type
(6) CS6364 50 Amp 125/250V Twist, (2) L6-30 30 Amp 250V Twist,
(2) L5-20 20 Amp 125V Twist GFCI
CEP6221CC 200 Amp 120/280V Cam Type
(8) L21-20 20 Amp 120/280V, (2) 5-20R 20 Amp 125V Straight GFCI
CEP6240CC 400 Amp 120/280V Cam Type
(8) Pin/Sleeve 60 Amp 125/250V, (2) 5-20R 20 Amp 125V Straight GFCI
CEP6241PC 400 Amp 120/280V Cam Type
(4) Pin/Sleeve 100 Amp 120/280V, (2) 5-20R 20 Amp 125V Straight GFCI
