STARRETT®
Electronic Calipers
799 Series
Light, comfortable, easy to use.
They have a slim, streamlined profile, function buttons for zero and
inch/mm, a large, clear, easy-to-read LCD display, and long battery
life.
All Sizes
•
Inch/millimeter conversion reads .0005" or 0.01mm
•
Easy access to single long-life battery
•
Last measuring position retained when shut off
•
Hardened stainless measuring surfaces for long life
•
Fine adjustment thumb wheel
•
Lock screw to hold the slide in position
•
Resolution: .0005" (0.01mm)
•
Zero at any position
6", 8" & 12" Calipers Only
•
Easy-to-read LCD, .32" high characters
•
Auto shut-off after 5 minutes of nonuse
•
Linear accuracy meets DIN862
•
Integrated depth rod
•
Jaw Depths: 6" Caliper - 1 1/2" outside, 5/8" inside; 8" Caliper - 2"
outside, 5/8" inside; 12" Caliper - 2 1/2" outside, 23/32" inside
Extended Range 24" & 40" Calipers
•
Preset and hold feature
•
Minimum and maximum limits set
•
I.D. jaw dimension is .800"/20.32mm
•
LCD characters are .50" high
•
Auto shut-off after 30 minutes of nonuse
STARRETT®
Offset Dial Caliper
120J Series
This too has an adjustable jaw for
versatility when measuring different
planes that can’t be reached with a
regular caliper. The reference jaw is adjustable in height to be either
longer or shorter than the sliding jaw.
•
Adjustable jaw-3-1/2” long
•
Extends up to 5/8” longer than the sliding jaws
STARRETT®
Dial Calipers
With Long Nib Jaws
120B Series
This tool is a direct reading caliper with 3” long jaws, ideal for heavy
duty use and for gaining access to more measuring area than with
conventional calipers. Strong inside and outside nibs measuring from
zero for outside measuring and from .300” for inside measuring
•
Also available in 0-300 mm range
STARRETT®
Micrometers
216 Series
Mechanical digital micrometer
•
The anvil and spindle are sized at
.250”
•
Clear, easily read numbers
reduce errors
•
No-glare black finish on the frame
•
Starrett no-glare satin chrome finish on thimble and sleeve
•
.001” or is read directly from the counter
•
.0001” is read from the vernier scale on the micrometer sleeve
•
Balanced frame design for comfortable and accurate measuring
•
Ring-type knurled lock nut for quick and
sure locking
•
Gracefully designed tapered frame for use in narrow slots and
tight places
•
A choice of smooth friction thimble for uniform pressure on the 1-4”
sizes or the combination ratchet and speeder for uniform pressure
and quicker adjustment on all sizes
•
Available in inch and millimeter models
•
Available in .001”, .0001” and .01 mm graduations
STARRETT®
Electronic Micrometer
734 Series
Full function electronic outside
micrometers with a full range of
features.
•
Large, high-contrast LCD digital
readout is easy to read and
reduces errors
•
Conventional inch or millimeter graduations standard
•
No-glare black wrinkle finish on the frame
•
Starrett no-glare satin chrome finish on thimble and sleeve
•
Balanced frame design for comfortable and accurate measuring
•
Ring-type knurled lock nut for quick and sure locking
•
Smooth friction thimble for uniform pressure
•
The anvil and spindle diameter is .250”
•
Tapered frame for use in narrow slots and tight places
•
Extremely hard and stable one-piece spindle
•
Micro-lapped carbide measuring faces
•
Includes one 3-volt battery for over one year’s normal usage
•
Automatic OFF after 30 minutes of nonuse
•
Instant inch/millimeter conversion (except on 734 metric-only
model)
•
Measurement HOLD button
•
Ability to zero tool at any position
•
Ability to retain and return to the true zero reading of the
micrometer
•
PRESET button to install any reading at any position
•
Ability to install minimum and maximum limits except on straight
metric models
Item #
Range
STR799A-6/150
0”-6”
STR799A-8/200
0”-8”
STR799A-12/300
0”-12”
STR799AZ-24/600 0”-24”
STR799AZ-40/1000 0”-40”
Item #
Range
STR120JZ-6
0-6”
Item #
Range
STR120B-12 0-12”
Item #
Range Measuring Surfaces
STR216RL-1
0-1”
Steel
STR216XRL-1
0-1”
Carbide
STR216RL-2
1-2”
Steel
STR216RL-3
2-3”
Steel
STR216RL-4
3-4”
Steel
STR216RL-5
4-5”
Steel
STR216RL-6
5-6”
Steel
Item #
Range
STR3734XFL-1 0”-1”, 0-25mm
