455
STABILA
Laser Measure
Type LD500
•
Camera Target Locator with 4X
Zoom
•
Built in Inclinometer - built in,
measures degrees, percent of
grade and slope
•
Stores last 20 measurements
•
Integrated Calculator – readings can be added to, multiplied,
subtracted from, etc.
PACIFIC LASER SYSTEMS
Laser Measure
PLS1
•
Accurate to 1/8 at 300 feet
•
Range: 300+ ft.
•
Memory of last 15 measurements.
•
Built-in 2X optical scope with
viewfinder for use in sunlight
•
Measures distance, area, square footage, height; can add,
subtract, multiply, take continuous trace measurements and
time-delayed readings
•
Bubble Vial
•
Power Supply: 2 AA batteries (included)
CST/BERGER
Fiberglass Leveling Rods
•
These Rugged, Rectangular-Shaped Leveling Rods are
made from, corrosion-resistant and non-conductive
fiberglass.
•
The rods feature abrasion-resistant coating with special
reinforcement fiberglass ribs to stop breakage and add
stability.
•
Easy-to-read graduations and a special measuring scale on
the backside permit users to read height at eye level.
•
Rods are equipped with reliable and long lasting spring
loaded Delrin® buttons.
•
All rods come with a carrying case.
•
Heavy Duty Telescoping Rods in 13'(4m), 16'(5m) and 25'(7.6m)
lengths.
•
Assembly is interchangeable between all sections.
•
Snug fitting telescoping sections minimize "side to side" and "front
to back" play.
•
Snap on "Rod level". (Optional)
CST/BERGER
Transit Levels
Grades & Elevations
Levels - Use for:
Determining grades & elevations,
rough angle turning, laying out &
leveling foundations, setting forms,
leveling walls, setting lines, setting
offset stakes, plumbing walls,
setting slope, truing forms, aligning
poles, fence posts
•
Non-strip focus knob prevents breakage and lens damage
•
Built-in sunshade reduces glare
•
Large achromatic coated objective lens for a sharp image
•
Rubber eyepiece cap protects eyeglasses
•
Durable brass leveling screws
•
Dust protected eyepiece with fixed cross hairs for accuracy
•
High precision glass level vials
•
4 1/2 foot (1.4m) short focus for maximum usable range
•
Sliding lock levers to lock telescope (on transit/levels)
•
One piece aircraft aluminum telescope
•
Electrostatically powder coated safety yellow paint
20X Econo Line Model 135 Level & 136 Transit-Level
Fast setup-simple to use. Model 135 is designed strictly for leveling,
and model 136 is used for leveling, plumbing, or running vertical
lines. Econo Line instruments have no circles or vertical arc. Units
have a 1/2" x 20 mounting thread. Both models provide 1/4" accuracy
at 100 feet (6mm at 30m) with a 200 foot (61m) working range.
Includes custom hard-shell carrying case, Allen wrench, and manual.
CST/BERGER
Transit Level Kits
Model 200B Transit-Level Kit; Includes
#60-ALQCI21 Tripod, #06-808C Rod
Use for: Determining grades & elevations,
rough angle turning, laying out & leveling
foundations, setting forms, leveling walls,
setting lines, setting offset stakes, plumbing
walls, setting slope, truing forms, aligning poles,
fence posts
•
Non-strip focus knob prevents breakage and
lens damage
•
Built-in sunshade reduces glare
•
Large achromatic coated objective lens for a sharp image
•
Rubber eyepiece cap protects eyeglasses
•
Durable brass leveling screws
•
Dust protected eyepiece with fixed cross hairs for accuracy
•
High precision glass level vials
•
4 1/2 foot (1.4m) short focus for maximum usable range
•
Sliding lock levers to lock telescope (on transit/levels)
•
One piece aircraft aluminum telescope
•
Electrostatically powder coated safety yellow paint
20X Speed Line Model 200B Transit-Level
Our most popular models with builders that require rough angle turn-
ing and fine tuning adjustments. Clamps and tangents bring your
instrument quickly on target. 15 minute horizontal circle on both mod-
els and 1° vertical arc on model 200B allow the builder to set rough
angles. Units have a 1/2" x 20 mounting thread. Provides 1/4" accu-
racy at 100 feet (6mm at 30m) with a 200 foot (61m) working range.
Includes custom hard-shell carrying case, Allen wrench, plumb bob
with string, and manual.
Item #
Accuracy
Range (radius) (ft.)
SB06500 ±1/16" over entire range
650
Item #
PACPLS1
Item #
CST06-916C
CST06-925C
Item #
Description
CST54-135K
Model 135 Level Kit; Includes
#60-ALQCI21 Tripod, #06-808C Rod
Item #
CST54-200K
