STARRETT®
Micrometer Depth Gages
445 Series
The depths of holes, slots,
shoulders and projections can be
measured to .001” with these tools. A
graduation of 0.001 mm is also
available. Gages are furnished with choices of 3”, 4” and 6” bases and
have 5/32” diameter measuring rods
•
Features a combination ratchet and speeder for uniform pressure
and quicker adjustment
•
Ring-type lock nut for quick and sure locking
STARRETT®
Telescoping
Hole and Slot Gages
579 Series
Telescoping gages, self centering,
with two telescoping arms. The
handles are rigidly attached to the
plungers and are automatically self-centering. Constant spring
tension gives uniform contact pressure and both plungers are easily
locked at any desired setting.
STARRETT®
Lock-Joint
Transfer Type Calipers
36 Series Outside and 37
Series Inside
Starrett Lock-Joint Transfer
Calipers have three key features…
a transfer arm, fine-adjustment
screw, and locking joint. The
transfer arm makes it possible to
transfer measurements from the
inside of chambered cavities, over flanges and other places where it
is necessary to move the
legs after they have been set to size. The adjusting screw permits
close adjustments for fine measurements. After the legs have been
set to approximate size and the joint locked, the final adjustment is
made by a few turns of the knurled adjusting nut.
•
Legs are made from high-grade steel
•
Sizes listed are the length of the legs.Their actual measuring
capacity is about one-third greater than the size of the legs
STARRETT®
Carpenters Dividers
92 Series
These dividers combine rigidity, light weight
and easy handling. The sturdy construction of
the joint, combined with the quadrant,
eliminates side deflection of the legs. A
quadrant adjusting nut permits
fine-adjustments for close measurements. A
check nut located between the legs locks the
legs firmly after the proper adjustment has
been made. This feature prevents the legs from moving in and out
with the grain on wood when scribing, or sliding off rough spots when
scribing on metals.
•
Legs are forged steel, tempered and highly polished
•
The adjustable point may be quickly removed and a common
pencil inserted in its place
•
The No. 92-9, 9" size is designed to accommodate a standard
long pencil, especially useful for carpenters
•
No. 88 Ball Points may be used with the No. 92 Series
•
Actual capacity is one-third greater than the listed size
Item #
Range Base
STR445AZ-3RL 0-3”
3”
STR445AZ-6RL 0-6”
3”
STR445AZ-9RL 0-9”
3”
STR445AZ-12RL 0-12”
3”
STR445BZ-3RL 0-3”
4”
STR445BZ-6RL 0-6”
4”
STR445BZ-9RL 0-9”
4”
STR445BZ-12RL 0-12”
4”
STR445DZ-3RL 0-3”
6”
STR445DZ-6RL 0-6”
6”
STR445DZ-9RL 0-9”
6”
STR445DZ-12RL 0-12”
6”
Item #
Range Handle Length (in.)
STR579A
⁵⁄₁₆
”-
¹⁄₂
”
2
³⁄₈
STR579A-8
⁵⁄₁₆
”-
¹⁄₂
”
8
STR579A-12
⁵⁄₁₆
”-
¹⁄₂
”
12
STR579B
¹⁄₂
”-
³⁄₄
”
2
³⁄₈
STR579B-8
¹⁄₂
”-
³⁄₄
”
8
STR579B-12
¹⁄₂
”-
³⁄₄
”
12
STR579C
³⁄₄
”-1
¹⁄₄
”
2
³⁄₈
STR579C-8
³⁄₄
”-1
¹⁄₄
”
8
STR579C-12
³⁄₄
”-1
¹⁄₄
”
12
STR579D 1
¹⁄₄
”-2
¹⁄₈
”
2
³⁄₈
STR579D-8 1
¹⁄₄
”-2
¹⁄₈
”
8
STR579D-12 1
¹⁄₄
”-2
¹⁄₈
”
12
STR579E 2
¹⁄₈
”-3
¹⁄₂
”
2
³⁄₈
STR579E-8 2
¹⁄₈
”-3
¹⁄₂
”
8
STR579E-12 2
¹⁄₈
”-3
¹⁄₂
”
12
STR579F
3
¹⁄₂
”-6”
3
¹⁄₄
STR579F-8
3
¹⁄₂
”-6”
8
STR579F-12 3
¹⁄₂
”-6”
12
Item #
Size (in.)
36 Series Outside Calipers
STR36-6
6
STR36-12
12
STR36-24
24
37 Series Inside Calipers
STR37-6
6
STR37-12
12
STR37-24
24
Item #
Size (in.)
STR92-6
6
STR92-9
9
