www.edgecs.com
94
Power Tools & Accessories
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
C.S. UNITEC, INC.
Pneumatic Cutoff Saw
•
Hand-held 14” saw cuts concrete,
asphalt, masonry, steel
•
Wet or dry cutting
•
Low maintenance - no belts,
pistons, fuel lines or carburetors
•
Accept diamond or abrasive
blades
•
Adjustable blade guard with built-in water connection
•
In-line oiler for motor lubrication
•
1” arbor size, 1/2” NPT air connection
C.S. UNITEC, INC.
Portable Magnetic Drill
•
Drills up to 2" diameter holes with annular
cutters, 7/8” diameter twist drill capacity
•
Strong 10.5 Amp motor and two-speed
gearbox
•
HD dual-coil magnet has holding strength of
3750 lbs.
•
Easy "twist and lock" keyless arbor for
cutters
•
Compact height of 16-1/2" allows drilling in
small spaces
C.S. UNITEC, INC.
Pneumatic Rotary Hammer
•
Uses SDS-Max Shank Drill Bits
•
Holes up to 1" diameter with solid
carbide tipped bits
•
Up to 3" diameter with carbide
core bits
•
Fast impact drilling of anchor
holes and thru holes for concrete and masonry
•
Safer than electric in hazardous atmospheres and wet
environments
•
Designed for use in refineries, chemical plants, utilities,
construction and heavy industry
C.S. UNITEC, INC.
Heavy-Duty
Concrete Grinder
With Dust Extraction
•
Remove paint, epoxy, glue and
other hard coatings
•
Clean concrete before applying
new paint or coatings
•
Long power tool life due to the
new motor arrangement
•
Grinds into corners and edges because of removable front dust
guard
•
Efficient dust exhaust outlet
HOUGEN MFG., INC.
Ultra Low Profile
Magnetic Drill
•
Ultra Low Profile - fits in the
tightest of spots. Only 6-11/16"
height
•
Uses RotaLoc™ cutters which
requiresno tools for installation or
removal
•
Positive slug ejection
•
High torque gearing
•
Feed handles lock for easy maneuverability
•
Ratchet or wrench can be used in place of handles
•
Rear mounted controls
HOUGEN MFG., INC.
Low Profile Magnetic Drill
•
Uses RotaLoc Plus™ cutters
which requires no tools for
installation or removal
•
Positive slug ejection
•
High torque gearing
•
Lift detector safety system
•
Feed handle switches easily from
side to side
•
Ratchet or wrench can be used in
place of feed handle
•
Rear mounted controls
Item # Power HP
Max Depth
of Cut (in.)
Max. Blade
Cap. (in.)
CFM @
100 psi
UCCSH-100
5
4
14
90
Item #
Power
Speed
Arbor
Bore (in.)
UCECO-50 10.5 Amp/
110 Volt
Gear 1: 250 RPM,
Gear 2: 450 RPM
³⁄₄
Item #
Speed
RPM BPM
Power/
Consumption
@ 90 PSI
Connection
(in.)
UC2-2414-0010 0-625 0-3000 0.7 HP/21 CFM 1/2 I.D.
Item #
Dia. (in.)
Speed Power Consumption
UCEBS-125-D 5 10,000 RPM 14 Amps/ 1500
Watts
Item # Dia. (Min/Max) Depth (in.) Motor
Speed
HGHMD115
¹⁄₂
” - 1
¹⁄₁₆
”
³⁄₄
”
8A 450 RPM
Item # Dia. (Min/Max) Depth (in.) Motor
Speed
HGHMD150
⁷⁄₁₆
” - 1
³⁄₈
”
1
8A 450 RPM
