HOUGEN MFG., INC.
Portable Magnetic Drills
•
Positive slug ejection
•
Feed handles quickly change from side to side
•
Lift detector safety system
•
Rear mounted controls
•
Gravity fed coolant system
•
Swivel Base adds even greater versatility
•
Great for horizontal, overhead, tight areas, and getting out over another piece of steel
HOUGEN MFG., INC.
Multi-Speed Portable Magnetic Drills
HMD 505 Features:
•
Two speed gear box - 250 & 450 RPM
•
Positive slug ejection
•
Two stage magnet. Engages full power when motor is turned on
•
Feed handles quickly change from side to side
•
Lift detector safety system
•
Rear mounted controls
•
Coolant bottle included
•
Optional pressurized coolant system available
HMD915 Features:
•
Interchangeable gears for up to five speeds (120/332 RPM included), (100, 120, 200, 332 and 400 RPM available)
•
Uses Rotabroach “42/43,000-Series” Cutters
•
Can use “12,000-Series” Cutters with adapter (Included) - (Part No. 40040)
•
Positive slug ejection
•
Feed handles quickly change from side to side
•
Coolant bottle included
•
More holding power with impactor points
•
Lift detector safety system
•
Chip breaker
HOUGEN MFG., INC.
Electro Hydraulic Hole Punch
Punch-Pro™
This heavy-duty model is built for punching up to 7/8" diameter holes in materials up to 3/8" thick. The addition of
eyebolts on both sides of the unit allows for easy attachment of a lift assist or a counter-balancer for improved
ergonomics. Its 3-15/16" throat depth adds to its versatility covering a wide range of work pieces. Easily confirm the hole
position with the jog down feature. Punch automatically returns to the starting position after the punching cycle is
complete. Work stand, foot switch, 13/16" punch & (2) dies and tool kit are included
Item #
Dia. (Min/Max)
Depth (Max)
Motor
Speed
Arbor
HGHMD904C
⁷⁄₁₆
” to 1
¹⁄₂
”
2”
8A (115V)
450 RPM Spring enjected
HGHMD925
⁷⁄₁₆
” to 1
¹⁄₂
” (1
¹⁄₄
” Pwr. Fd.)
2”
8A (115V)
450 RPM Spring
HGHMD914
⁷⁄₁₆
” to 2
¹⁄₁₆
”
3”10.5A 11.2A (115V) 350 RPM Spring
¹⁄₂
” Low Buck Chuck with Key
HG10731
Item #
Dia. (Min/
Max)
Depth (in.)
Motor
HGHMD505
⁷⁄₁₆
” - 2
³⁄₈
”
3
14A
HGHMD915
³⁄₄
” - 3
¹⁄₁₆
”
3
10A
Item # Pressure (Tons)
Approximate
Punching Speed
Maximum Hole Size -
Round
Maximum Hole Size-
Oblong
Motor
HG75005
27.5
3 seconds
⁷⁄₈
"
¹¹⁄₁₆
" x
¹³⁄₁₆
"
12.2 A
