93
WMH TOOL GROUP
9”
Horizontal Bandsaw
JET
•
Large handwheel and built-in
gauge for easy blade tensioning
•
Coolant is distributed through the
blade guides
•
Blade guides feature parallel
double row ball bearing support
•
Blade brush is built-in and self-
propelled
•
Quick-positioning vise with fully adjustable jaws swivels to 45°
•
Removable chip tray for quick clean-up
•
Blade is fully guarded regardless of blade guide position
•
Fully adjustable hydraulic downfeed with separate on/off valve
•
Automatic shut-off after cut
•
Carbide blade guides with rollers
•
Coolant system
•
4/6VT Bi-metal blade
•
Adjustable material stop
Specifications:
•
Round Capacity @ 90°: 9 in.
•
Round Capacity @ 45°: 9 in.
•
Rectangle Capacity @ 90°: 2 in. x 16 in. - 9 in. x 14 in.
•
Rectangle Capacity @ 45°: 9 in. x 6-1/8 in.
•
Blade Speeds (SFPM): 82, 132, 170, 235
WMH TOOL GROUP
7” X 12”
Horizontal/Vertical
Bandsaw
JET
•
UL listed motor
•
Heavy cast iron bow and bed
•
Hydraulic downfeed for ease of cut
•
Hardened and ground worm gear
•
Roller cabinet with built-in chip tray
•
Automatic shut-off after cut
Standard Equipment:
•
Vertical worktable
•
Coolant system
•
3/4" Bi-metal blade
•
Adjustable material stop
•
Chip brush
Specifications:
•
Round Capacity @ 90°: 7 in.
•
Round Capacity @ 45°: 4-1/2 in.
•
Rectangle Capacity @ 90°: 2 in. x 12 in. - 7 in. x 8-1/2 in.
•
Rectangle Capacity @ 45°: 7 in. x 5 in.
•
Blade Speeds (SFPM): 80, 130, 180, 285
WMH TOOL GROUP
20” Floor Drill Press
JET
•
Hinged metal belt and pulley cover coupled with
quick adjustment motor mount allow rapid
changing of spindle speeds
•
Rotating, 45° tilting, crank-operated worktable
with quick release clamp
•
On/off switch located on front of the drill press
head
•
A 1/2" diameter external positive depth stop with
three nut locking feature for quick adjustment
•
Adjustable tension spindle return spring
•
Spindle is supported by high quality ball bearings
•
Built-in work lamp on all models, bulb not included
•
Drill chuck and key included
Specifications:
•
Drilling Capacity: 1 in.
•
Chuck Size: 3/4 in.
•
Spindle Travel: 4-5/8 in.
•
Spindle Distance to Base: 46-3/4 in.
•
Spindle Distance to Table (max/min): 18-5/8 in. / 16-1/8 in.
•
Number of Spindle Speeds: 12
•
Range of Spindle Speeds (RPM): 150-4,200
•
Motor: 1-1/2 HP
C.S. UNITEC, INC.
Portable
Electric Hacksaw
•
Ideal for cutting of pipe, structural
steel, tanks and other materials
•
Compact size, ideal for cutting in
confined spaces
•
2-3/8" blade stroke
•
Pipe clamps for 90° cutting of up to 24" OD pipe
•
Profile clamps for structural steel
•
Optional blade guide to ensure right-angle cuts
C.S. UNITEC, INC.
Portable
Electric Bandsaws
•
Capacity: 7”
•
5.8 Amps
•
Ideal for plumbing and mechanical contractors, as well as demoli-
tion and plant maintenance
•
Heavy-duty variable-speed motors operate on 110VAC
•
With stainless steel housing and planetary gearbox cut up to 7"
OD
•
Fast on-site cutting
•
Speed: 100-245 RPM
Item #
JEHBS-916W
Item #
JEHVBS-7MW
Item #
JEJPD-20MF
Item #
Desc.
Amps/Volts Stokes Per Min
UC5-1215-0070
1.5 HP,
w/trigger throttle
11/110
200-400
Item #
UC5-6047-0010
