www.edgecs.com
326
Safety & Security
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
MILLER BY HONEYWELL
Rescue Descent Device
SafEscape ELITE™
•
Meets All Applicable Safety
Standards Globally
•
Only rescue and descent device
on the market that meets the very
stringent, European EN341/2008
Standard
•
No Annual Factory Recertification
– 7-year interval before an unused
unit is required for recertification
•
User-Rated for Up to Two (2) Workers.
•
Designed for self-rescue, assisted rescue or provides the
capability for more users to evacuate in a short period of time.
•
Approved for Multiple Descents
•
Bi-Directional Design, as a descent is initiated, the other end of
the rope is ascending readying itself for another rescue
•
Descent Loads:
•
1 person 66 - 330 lbs.
•
2 person 66 - 551 lbs.
•
Max. Descent Height:
•
1 person 1640 ft.
•
2 person 656 ft. (200 m)
•
Hoisting Capacity: 220 lbs. up to 11 ft. max 10 lifts
•
In Emergency: 617 lbs. up to 33 ft. max 1 lift
•
Descent Speed: 3.3 ft./sec at 220 lbs.
•
OSHA, ANSI/ASSE Z359.4, prEN341:2008/1A, EN1496:2007/B,
CE0123, ISO22159:07/1/A
MILLER BY HONEYWELL
Ladder Climbing Safety Systems
with Automatic Pass-Through
Vi-Go™
•
Sleeves – Designed to follow the
user along the lifeline while
ascending or descending, instantly
locking in the event of a fall
•
Uninterrupted fall protection – Sleeve
automatically bypasses
intermediate cable guides, keeping
both hands free for climbing; travels
smoothly along cable and locks
instantly in the event of a fall
•
Easy, one-hand operation for
attachment/detachment from the
system
•
Automatic pass-through cable guides secure lifeline to prevent
cable wear and enable the system to accommodate curves
•
Withstand Harsh Environments – Constructed with durable,
corrosion-resistant aluminum and stainless steel components
•
Attachment mechanism engineered to prevent incorrect
installation, ensuring greater safety. Unit will not open if attached
incorrectly
•
Accommodates 5/16” or 3/8” cable
GUARDIAN FALL PROTECTION
Full Body Construction Harness
Seraph
•
Shoulder pads
•
Six points of adjustment
•
Stretch points in shoulders
•
Sub pelvic strap
•
Quick adjust torso buckles
•
Padded waist belt
•
Lanyard keepers
•
Rescue O-rings
•
A special identification label allows for your employees to
personalize their harness without jeopardizing the integrity of the
webbing
•
Impact indicator & inspection log tag
•
Hammer loops
•
Tongue buckle leg straps
Item #
Description
MYSEWPKT/XFT
Wind Energy Kit Includes:
Miller SafEscape ELITE RDD
with hoisting wheel and ladder bracket,
T-bar, edge protector, 3 anchor slings,
3 carabiners, pulley, adjustable rope
anchor, rescue rope grab,
accessory bag and kit bag.
MYSECRKT/XFT
Crane Rescue Kit Includes:
Miller SafEscape ELITE
RDD, rescue harness, cross-arm strap,
retrieval yoke and rescue bag
MYSEHW/XFT
SafEscape ELITE RDD
w/Hoisting Wheel includes: anchor
slings and rescue bag
MYSEHWLB/XFT
SafEscape ELITE RDD
w/Hoisting Wheel & Ladder Bracket
Includes: anchor slings,adjustable rope
anchor and rescue bag
Item #
Length (ft.)
# of Cable
Guides
MYVG/30FT
30
0
MYVG/50FT
50
1
MYVG/70FT
70
1
MYVG/110FT
110
2
Item #
Size
GU11174
S
GU11170
M-L
GU11173 M-L, w/side D-rings
GU11172
XL
GU11171 XL, w/side D-rings
Workplace
safety is
everybodys
business.
