GUARDIAN FALL PROTECTION
Permanent Roof
Anchor
CB-12 & CB-18
•
Universal base plate
•
Durable galvanized finish
•
Fasteners provided for wood &
steel
•
For use on wood, steel or concrete
•
Post extends past roofing substrate
to keep attachment point high enough that it is still accessible after
the roof is complete
•
Round post works with most off-the-shelf flashing kits
•
Great for use with retractable or horizontal lifeline systems
•
Swivel top anchor point option available
•
Ask about different anchoring options (standard base to plywood
or metal deck, attachment with backer plate, weld on)
GUARDIAN FALL PROTECTION
4-Way Plate Anchor
•
Supports one worker in fall arrest
or two in fall restraint
•
If used with an horizontal lifeline, it
supports two workers in fall arrest
or four in fall restraint
•
Constructed of hot rolled steel
•
Applicable for wood, metal, and concrete applications
•
4 connection points
•
90-degree angles between connection points
GUARDIAN FALL PROTECTION
Standing Seam Roof Clamp
•
Two-Way Universal Standing Seam
Clamp
•
Unique, reversible design allows for
seams up to 1" wide
•
MR-24, VSR or similar profiles can be
covered with one clamp
•
Durable, all steel construction with zinc
electroplate finish
GUARDIAN FALL PROTECTION
Ridge-It Anchor
•
Designed for permanent use on wood
rooftops
•
Manufactured with 2 D-rings and is 17—3/8
inches in length
•
Composed of stainless steel for maximum
durability
•
Compliant with all applicable OSHA and
ANSI regulations
GUARDIAN FALL PROTECTION
Concrete Anchor Strap
•
As a disposable anchor point,
can be used in other applications
such as wood framing members,
rebar, pipe racking, etc.
•
As always, make sure that your anchor strap is attached to a struc-
ture capable of supporting 5,000 lbs.
•
6 ft. long
GUARDIAN FALL PROTECTION
Swivel Anchor Point
The MEGA Swivel incorporates a custom design
to its components to give it’s incredible strength.
The D-Ring used a heavy gauge heat treated
steel, Reinforced Bridge and Locking Caps. The
Locking Caps slot into the Swivel Housing
preventing the D-Ring from spreading outwards
during heavy loads. The Bridge keeps the D-Ring
from collapsing. The Swivel Housing allows the
D-Ring to flip back and forth as wells rotate at 360
degrees.
SPECIFICATIONS
•
Safe working load: 2,000 lbs
•
Ultimate breaking strength: 10,000 lbs
•
Material: Drop forged alloy steel
•
Hardware for concrete: Custom designed bolt (3,000 psi)
•
Hardware for steel: 5/8” grade 8 bolt, lock washer & nut
•
Rates for 4 men HLL systems
•
Rotates 360° degrees
•
Flips 180° degrees
•
Used for steel flanges or concrete substrate
Item #
Size
Application
GU00645 12” post
Wood/Steel/Concrete
GU00656 18” post
Concrete
GU00657 18” Post
Wood/Steel
Item #
GU00691
Item #
GU10600
Item #
GU00510
Item #
GU10717
Item #
Base Material
GU0237
Steel
GU0238
Concrete
