www.edgecs.com
334
Safety & Security
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
GUARDIAN FALL PROTECTION
C-Slab Grabber
•
An ideal solution for installing guardrails during
concrete decking operations
•
With the C-Slab Grabber’s new backup safety pin
(that keeps the systems from separating), quick
adjust handle, and anti-slip tape, this product
easily meets or exceeds OSHA’s safety standards
•
Fast and easy to set up and adjusts up to a 36"
slab
•
The rails that can be used with this product
include: 2x4’s, 2x6’s, or cable for rails
•
The maximum spacing between each grabber is (8') apart
GUARDIAN FALL PROTECTION
Parapet Clamp Guardrail
System
•
Economical and easy-to-use system
•
Each system includes a parapet clamp
and guardrail post
•
Not designed as an anchorage point for
a fall protection system
•
When working near a leading edge,
always use a personal fall arrest or
restraint system.
•
Can be easily installed by one person
without ladders or scaffolding
•
Adjusts to wall widths between 4" to 24"
•
Complies with OSHA standards
•
Maximum spacing 8' apart
GUARDIAN FALL PROTECTION
Parapet Anchor system
•
Can be used for the placement of guardrail
uprights, single point tie-off, or in conjunction
with a horizontal rope lifeline (up to a twenty
foot span)
•
Meets OSHA standards for guardrail and
anchor point purposes
•
Can fit a wall from four inches (4") to twenty
inches (20") in width
•
Reinforced for long life
•
Rated for 5,000 pounds
•
Can be used with shock absorbing lanyards and retractables
•
Large easy-to-grip adjustment handles for quick set-up and proper
securement
•
Only one option may be performed at a given time (e.g., You
cannot use the guardrail system while using the single point tie-off)
•
Works with 52" Guardrail Post
•
Workers can incorporate Horizontal Rope Lifeline System up to a
20 ft. span for increased mobility for one worker only
GUARDIAN FALL PROTECTION
Residential Guardrail System
•
System is a roof bracket designed with a
guardrail holder and bracing support
•
Roof bracket is adjustable from 6/12 to 12/12,
proving it to be very versatile
•
Lightweight system is slotted for easy removal
and compact for storage
•
Can be used as a slide guard or guardrail for
sloped roofs
•
Maximum spacing between these systems is
8' apart
•
When this system is used in conjunction with 2x4 and 2x6 toe
boards, the system complies with OSHA regulations
•
Roof Bracket includes Guardrail Holder and Bracing Support
GUARDIAN FALL PROTECTION
Guardrail Post
•
Designed to work in conjunction with The Residential
Guardrail System or Parapet Clamp Guardrail System
•
Post stands 42” in height
•
Maximum spacing between each post is 8'
GUARDIAN FALL PROTECTION
End Rail
•
Caps off platform ends of stacker bracket by
installing easily onto universal guardrail posts
•
Composed of lightweight welded steel and
measures 3' in height.
GUARDIAN FALL PROTECTION
Stacker Bracket Frame
•
The main support to the Stacker Bracket
system
•
Frame itself is composed of durable
welded steel and is great for eaves up to
18" in size
•
Platform extends 17" below the top plate
and rails hang twenty-eight inches away
from the wall
•
Rails are 28” out from wall
Item #
Weight (lbs.)
QC15500
21.80
Item #
Weight (lbs.)
QC15170
19.00
Item #
Weight (lbs.)
QC15171
19.00
Item #
Weight (lbs.)
QC15173
19.00
Item #
Weight
(lbs.)
QC15175
4.00
Item #
QC61128
Item #
QC61129
