331
GUARDIAN FALL PROTECTION
Temper Reusable Anchor
•
Reusable anchorage connector designed for
temporary use on wood rooftops
•
Fits all roof pitches from flat to 12/12
•
Composed of thick plated steel for longer
lasting product life
•
Can be installed with either screws or duplex
nails (depending on roof pitch), and its
designed offset holes down the center help
keep the truss from splitting
•
Supplied with all necessary fasteners (always use new fasteners
for each new installation application)
•
Instructions silk screened onto anchor for durability
GUARDIAN FALL PROTECTION
Beam Anchor
Beamer™ 2000
•
Designed specifically for use at
your feet and overhead (use Big Boss lanyard for use at feet)
•
Nylon bushings provide smooth movement along beam & act as
an impact indicator in the event of a fall
•
Fits 3.5" - 14" beams
•
Weather-resistant
•
Reusable and extremely durable
•
Ratcheting end piece
•
Lightweight
•
Slides easily in both directions
•
Welding spatter does not stick to aluminum bar
•
No tools are needed for fast installation
•
Precision machined aluminum bar
•
One handed operation
GUARDIAN FALL PROTECTION
Concrete Grip Anchor
•
Designed for use in cured
concrete with a compression strength of at least 3000 psi
•
Reusable, temporary
•
Installation is easy, just compress spring and insert cable shaft into
hole
•
Great for anchoring scaffolding
•
For use on vertical, or overhead applications
•
Designed for single user connection
GUARDIAN FALL PROTECTION
BMR Trolley Anchor
•
Fall Arrest anchor designed to be
used in combination with either a
shock absorbing lanyard, or a SRL
•
May also be used for Restraint and
Work Positioning applications
•
Rollers allow for smooth travel
around the work area while always
remaining tied off, and its safety
locking toggles allow for both easy
adjustment and eliminate the risk
of accidental clamp slippage
•
For use by one worker with a combined weight (including all tools
and equipment) of up to 310 pounds
•
Web/D-Ring connection point
•
Easy pin adjustment
•
Spring Material: Stainless Steel
•
Load Bar Material: Aluminum Alloy 7075-T6
•
Clamps (Jaws): Aluminum Alloy 7075-T6
•
D-Ring Material: Steel Alloy SAE4140-Nickel Plating
•
Webbing Material: Polyester
GUARDIAN FALL PROTECTION
3-Way Rescue Retrieval
Retractable Lifeline
•
Easy handle feature allows for quick
adjustment
•
High-quality machined parts make the
product durable and dependable
•
Proprietary design of internal mechanisms
•
Capacity: 310 lbs.
•
Max. Arresting Force: 900 lbs.
•
Max. Arresting Distance: 42”
•
Average Locking Speed: 4-1/2 ft./sec.
GUARDIAN FALL PROTECTION
Arc-O-Pod
Rescue & Retrieval Kit
•
7 ft. aluminum tripod is lightweight and
portable
•
Adjustable locking legs adjust quickly in
increments of 2" and are kept in position with
locking push pins - and will span a 5-1/2 ft.
diameter hole
•
Complete with safety chain to prevent move-
ment and safety shoes that incorporate a rub-
ber sole for flat surfaces and spiked edges for
slippery surfaces
•
Heat-treated cast aluminum head incorporates a built-in pulley
system to rout lifeline of mechanical device directly over opening;
also equipped with drop-forged steel eyebolts for use as
anchorage point for secondary or back-up system
•
Complete with quick-mount bracket for attachment of Guardian
3-Way mechanical device for ease of use
•
Rated working load is 350 lbs. for work support and 310 lbs. for fall
arrest and can withstand up to 5,000 lbs. of vertical pull
•
Comes with bag, bracket, pulley, chains
Item #
GU00455
Item #
Desc.
GU00101 Fits 3
¹⁄₂
" to 14" beams up to 1
¹⁄₄
" thick,
for use on top or bottom flange
Item #
Desc.
GU00235 5,000 lb.
³⁄₄
" Hole, 3” Deep Min.
GU00236 10,000 lb. 1” Hole, 4
¹⁄₂
” Deep Min.
Item #
Desc.
GU00215 Trolley Anchor
Item #
Desc.
GU10974
50’
10981
65’
Item #
GU15030
