493
UNISTRUT
Telestrut Tubing
P9200 1-7/8”
•
12 Gauge Nominal Thickness
.105" (2.7mm)
•
P1000 and P9000 telescope inside
•
Allowable Moment (in-Lbs): 14,390
•
Wt./100’: 223 lbs
•
Ask about Telestrut post bases, fittings, and pins
•
See also: Telespar product
•
Call to specify material, finish and length
UNISTRUT
Channel Nut
P10XX With Spring
For use with Channel P1000, P1100, P2000,
P3000
•
Call to specify material and finish
UNISTRUT
Channel Nuts
P40XX With Spring
•
For Use with Channel P3300,
P4000, P4100
•
Call to specify material and finish
UNISTRUT
Channel Nut
P5510 With Spring
•
For Use with Channel P5500 only
•
Call to specify material and finish
UNISTRUT
Channel Nut
P30XX Without Spring
•
For use with P1000, P1100, P2000,
P3000, P3300, P4000, P4100,
P5000, and P5500
•
Call to specify material and finish
UNISTRUT
Channel Nut
P10XX With Plastic Retainer
For use with Channel P1000, P1100,
P2000, P3000, P5000, P5500
•
Special plastic retaining feature
•
Call to specify material and finish
UNISTRUT
Channel Stud Nut
P2380 With Spring
•
Nut Size Thread: 3/8” -16
•
A Stud Size: 1
¹⁄₈
”
•
B Thread Size: 7/8”
•
For Use With: P100, P1100, P2000, P3000
•
All stud nut grooves are serrated
•
Call to specify material and finish
Item #
UTP9200
Item #
Nut Size Thread
UTP1006-1420
¹⁄₄
”-20
UTP1007
⁵⁄₁₆
”-18
UTP1008
³⁄₈
”-16
UTP1009
⁷⁄₁₆
”-14
UTP1010S
¹⁄₂
”-13
UTP1012S
⁵⁄₈
” -11
UTP1023S
³⁄₄
” -10
UTP1024S
⁷⁄₈
” -9
Item #
Nut Size
UTP4006-1420
¹⁄₄
” -20
UTP4008
³⁄₈
” -16
UTP4010
¹⁄₂
” -13
UTP4012S
⁵⁄₈
”-11
Item #
Nut Size
UTP5510
¹⁄₂
” -13
Item #
Nut Size
UTP3006-0832 #8-32
UTP3006-1024 #10-24
UTP3006-1420
¹⁄₄
”-20
UTP3007
⁵⁄₁₆
”-18
UTP3008
³⁄₈
” -16
UTP3009
⁷⁄₁₆
”-14
UTP3010
¹⁄₂
” -13
UTP3013
¹⁄₂
” -13
Item #
Nut Size Thread
UTP1006T1420
¹⁄₄
” -20
UTP1008T
³⁄₈
” -16
UTP1010T
¹⁄₂
” -13
UTP1012
⁵⁄₈
” -11
UTP1023
³⁄₄
” -11
Item #
UTP2380-2
