UNISTRUT
Beam Clamp
P1796S
•
Use in pairs only
•
1/2” - 13 x 1
¹⁄₂
” Set screw included
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P2785
•
For use with Beams up to 3/4"
(19.1)
•
Flanges and with Channels
P1000, P1100, P2000, P3000,
P3300, P3301, P4000, P4001,
P4100, and P4101
•
Use in pairs only
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P2786
•
For use with Beams up to 3/4"
(19.1)
•
Flanges and with channels P1001,
P1101, P2001, P3001, P5000, and
P5500
•
Use in pairs only
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P2787
•
For use with Beams up to 3/4" (19.1)
•
Flanges and with Channels P5001
and P5501
•
Use in pairs only
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P2868
•
Beam Size A: 4” - 6”
•
Includes: Center Rod, "U" Bolts
and Hex Nuts
•
For use with Channels P1000,
P1100, P2000, P3000, P3300,
P3301, P4000, P4001, P4100, and
P4101
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P8000 & P8001
Malleable
•
Provides structural attachment to top or
bottom of metal beams, purlins, channel or
angle iron
Features:
•
Set screw made of hardened steel
•
Complies with Federal Specification
A-A-192A (Type 19) and MSS SP-69 (Type 19)
UNISTRUT
Beam Clamp
P289X
•
Material: Malleable Iron
•
7/8" Maximum Flange Thickness
•
Call to specify material and finish
Item #
UTP1796S
Item #
Design
Load (Lbs)
UTP2785
1,000
Item #
Design
Load (Lbs)
UTP2786
1,000
Item #
Design
Load (Lbs)
UTP2787
1,000
Item #
UTP2868
Item #
Rod Size
Max Load
Top
Max Load
Bottom
UTP8000EG
³⁄₈
”
500
250
UTP8000PL
³⁄₈
”
500
250
UTP8001EG
¹⁄₂
”
950
760
UTP8001PL
¹⁄₂
”
950
760
Item #
Rod Size ‘A’ Size ‘B’ Size
Load Rat-
ing (lbs.)
UTP2894-37
³⁄₈
”
2”
2”
350
UTP2894-50
¹⁄₂
”
2
⁵⁄₈
”
2
¹⁄₂
”
400
