511
UNISTRUT
Fiberglass
Post Base
UNISTRUT
Fiberglass
Ridgid Pipe Clamps
•
Rigid Pipe Clamps resemble the
more traditional style of pipe clamps
and are sized based on the pipe
inside diameter or nominal size
•
Polyurethane clamps are recommended for applications up to
160ºF; for high temperature applications (up to 230ºF)
•
Care should be taken not to exceed the recommended torque
values of the rigid pipe clamps
•
Material: Glass-reinforced polyurethane
•
Design Loads: Type 1 - 225 lbs.; Type 2 - 90 lbs.
•
FRP Bolt Size: 3/8” x 1-1/4”
•
Torque (ft./lbs.): 3
•
Wt/100 pcs. (lbs.): 5
UNISTRUT
Fiberglass
Clevis Hangers
•
Material: Glass-reinforced polyester resin
•
Size Range: 1
¹⁄₂
” - 2”
•
Hanger Rod: 1/2”
•
Trans Rod: 3/8”
•
Spreader Rod O.D.: 1/2”
•
Loads: 60 lbs.
•
Dimensions (T x H x H1 x W): 1/8” x 3
¹⁄₂
” x 2
³⁄₈
” x 1
¹⁄₂
”
•
Wt/Per 100 pcs. (lbs.) 25
UNISTRUT
Walkway Grating
G6XXXX
•
Specify Height: 1-1/2”, 2-1/2” or 4”
•
Specify gauge: 14 or 18
•
Specify leg shape: double-male or
male-female
•
Specify surface: slotted-smooth or
anti-skid
•
Finish is PG: Call for other material
options
UNISTRUT
Walkway Grating
G9XXXX
•
Specify Height: 1-1/2”, 2-1/2” or 4”
•
Specify gauge: 14 or 18
•
Specify leg shape: double-male or
male-female
•
Specify surface: slotted-smooth or
anti-skid
•
Finish is PG: Call for other material
options
UNISTRUT
Walkway Grating
Heel/Toe Side Plates
Forms a curb along grating length
that defines a structures side edge,
and helps contain loose objects.
•
14 gauge
Item #
UT20PU-5853
Item # Nom. Size Rigid Metal
UTPCR-050
¹⁄₂
”
0.840”
UTPCR-075
³⁄₄
”
1.050”
UTPCR-100
1”
1.315”
UTPCR-125 1
¹⁄₄
”
1.660”
UTPCR-150 1
¹⁄₂
”
1.900”
UTPCR-200
2”
2.375”
Item #
UTF100-1501
Item # Width (in.)
UTG6XXXX 6
Item # Width (in.)
UTG9XXXX 9
Item # Height (in.) Length (ft.)
UTG601PG 4
24
UTG631PG 6
¹⁄₂
24
UTG621PG 8
12
