513
ERICO/CADDY
Universal Beam Clamp
ERICO/CADDY
Beam Clamp
Rod Lock
Caddy Rod Lock provides a quick and
economical solution for installing
electrical and mechanical systems
supported by threaded rod. The system includes the Caddy Rod Lock
beam clamp and channel nut. Simply push the threaded rod through
the mounting hole and it instantly locks into position. The system can
even be used on threaded rod with slightly damaged threads or minor
burrs.
•
Fits 3/8” rod
•
Load Rating for flanges 1/8"-5/16" is 250 lbs. and for flanges
3/8"-7/16" is 500 lbs.
•
UL® 203 & UL 2239 Approved
•
FM® Approved
•
CRLB37EG Beam Clamp is FM Approved when installed in the
bottom mount orientation
•
CRLB37EG Beam Clamp is UL Listed for Fire Sprinkler
Applications when a lock nut is installed on the threaded rod on
the bottom side of the beam clamp
•
For use on plain and electrogalvanized (EG) hardware only.
•
Electrogalvanizd ductile iron
•
3:1 Safety Factor
ERICO/CADDY
Rod Lock Channel nut
Caddy Rod Lock provides a quick and
economical solution for installing
electrical and mechanical systems
supported by threaded rod. The system
includes the Caddy Rod Lock beam clamp and channel nut. Simply
push the threaded rod through the mounting hole and it instantly
locks into position. The system can even be used on threaded rod
with slightly damaged threads or minor burrs.
•
Removable hex nut for use on half-slot side of strut
•
Load capacity up to 750 lbs
•
Electro-galvanized forged steel
•
For use on plain and electrogalvanized hardware only
ERICO/CADDY
Strut Nuts
Caddy® Slick™
Traditional spring nuts are
dependent on strut depths. The SLICK nut has eliminated the spring and easily fits all standard strut depths -
reducing inventory by 75%. They are available in 1/4"-20, 3/8"-16 and 1/2"-12 sizes.
Box Quantity: 100
Item #
Rod Size Flange Thickness (in.) Rec# Load (lbs.) Bottom Rec# Load (lbs.) Top Finish
ES30000037EG
³⁄₈
”-16
³⁄₄
250 [Max]
500 [Max]
EG
ES3000037PL
³⁄₈
”-16
³⁄₄
250 [Max]
500 [Max]
PL
ES3000050EG
¹⁄₂
”-13
³⁄₄
760 [Max]
950 [Max]
EG
ES3000050PL
¹⁄₂
”-13
³⁄₄
760 [Max]
950 [Max]
PL
ES3000062PL
⁵⁄₈
”-11
³⁄₄
760 [Max]
950 [Max]
PL
Item #
CACRLB37EG
Item #
CACRLS37EG
Item #
Thread Size
Recommended
Torque (ft.-lbs.) F1 Load# (12 ga.) F1 Load# (14 ga.) F2 Load# (12 ga.) F2 Load# (14 ga.)
CASLICK250
¹⁄₄
in. - 20
5
250
150
800
800
CASLICK375
³⁄₈
in. - 16
15
400
300
1100
1000
CASLICK500
¹⁄₂
in. - 13
20
650
550
1250
1100
